ABB Residual Current Device 25A, 2-Pole, 10mA Sensitivity, Type AC, 1kA Breaking Capacity, 400V AC DDA200

Free Delivery in India | Lowest Global Shipping Charges

ABB Residual Current Device 25A, 2-Pole, 10mA Sensitivity, Type AC, 1kA Breaking Capacity, 400V AC DDA200



Category Residual Current Device Brand ABB Condition New

Specifications

Country of Origin	Italy
Brand	ABB
Height	85mm
Model	DDA200
Depth	93mm
Width	69mm
Mount Type	DIN Rail
Current Rating	25A
Series	DDA200
Terminal type	Screw
Breaking Capacity	1kA
Number of Poles	2
Standards/Approvals	IEC/EN 61008, RoHS
Rated AC Voltage	400V ac
Tripping Characteristics	Type AC
Tripping Mechanism	Electromagnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	10mA
Break Time	Instantaneous
Earth Leakage Protection Type	AC

Key Features

This device features 2 poles and a trip sensitivity of 10mA for AC type tripping characteristics.
It is designed for DIN rail mounting with screw terminal type.
Breaking capacity is rated at 1kA at 400V AC voltage.
The device utilizes electromagnetic tripping mechanism and toggle switch reset actuator.
Approved to IEC/EN 61008 standards and RoHS compliant with country of origin Italy.
Compact dimensions of 85mm height, 69mm width, and 93mm depth suit residential and industrial applications.

Product Description

ABB model DDA200 Residual Current Device (RCD) provides earth leakage protection designed for residential, commercial, and industrial electrical installations. It has a rated current of 25A and is a 2-pole device for effective protection against sinusoidal alternating earth fault currents.

The device has a trip sensitivity of 10mA, characterized as Type AC, ensuring sensitive detection and instantaneous break time to prevent electric shock hazards. The DDA200 series is compatible for assembly with ABB's S200 series miniature circuit breakers (MCBs) and is suitable for DIN rail mounting with screw-type terminals.

This RCD features an electromagnetic tripping mechanism and a toggle switch as a reset actuator for reliable operation. Breaking capacity is rated at 1kA at a voltage rating of 400V AC, making it robust for various electrical protection scenarios.

It conforms to IEC/EN 61008 and RoHS standards, affirming its quality and regulatory compliance. The country of origin for this product is Italy. This RCD is ideal for enhancing electrical safety in industrial, commercial, and residential environments.

The compact form factor with a height of 85mm, width of 69mm, and depth of 93mm allows flexible installation in electrical distribution boards. Earth leakage protection type is AC, addressing alternating current fault protection requirements.

The device uses screw terminals ensuring secure and standard-compliant electrical connections. Its electromagnetic tripping mechanism ensures instant response to leakage currents. For professional electrical installations and replacements, this ABB DDA200 RCD is a reliable choice.
