Siemens xEffect Miniature Circuit Breaker 1-Pole 2A Type C 240V AC 48V DC 10kA Breaking Capacity 278662 FAZ-C2/1N

Free Delivery in India | Lowest Global Shipping Charges

Siemens xEffect Miniature Circuit Breaker 1-Pole 2A Type C 240V AC 48V DC 10kA Breaking Capacity 278662 FAZ-C2/1N

Name: Siemens xEffect Miniature Circuit Breaker 1-Pole 2A Type C 240V AC 48V DC 10kA Breaking Capacity 278662 FAZ-C2/1N
Brand: Siemens
SKU: 136832
Price: 114.43 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Siemens Condition New

Specifications

Country of Origin	Romania
Range	xEffect
Brand	Siemens
Model	278662 FAZ-C2/1N
Depth	80mm
IP Rating	IP20
Width	66mm
Mount Type	DIN Rail
Current Rating	2A
Series	FAZ
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	1
Rated AC Voltage	240V ac
Rated DC Voltage	48V dc
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous
Cooper Bussmann 30A Fuse Block, 600VBrand	Cooper Bussmann

Key Features

Designed for 1-pole plus neutral electrical installations.
Rated for 240V AC and 48V DC applications.
Equipped with Type C tripping characteristics ideal for motor and transformer inrush currents.
Instantaneous break time for prompt fault clearing to protect circuits.
Features toggle switch for simple reset after operation.
Compact DIN rail mount with dimensions 66mm width and 80mm depth.
IP20 protection rating suitable for indoor electrical panels.
Thermal-magnetic trip mechanism ensures both overload and short circuit protection.

Product Description

Eaton 278662 FAZ-C2/1N Miniature Circuit Breaker is a high-performance 1-pole device rated at 2A current with Type C tripping characteristics, designed to provide reliable electrical protection in residential, commercial, and industrial installations. It operates at a rated AC voltage of 240V and a DC voltage of 48V, making it versatile for diverse applications.

The circuit breaker features a compact design with a width of 66mm and depth of 80mm, optimized for DIN rail mounting in control panels and switchboards. Its thermal-magnetic tripping mechanism combines thermal protection against sustained overloads with magnetic protection for instantaneous response to short circuits, enhancing overall safety.

Equipped with a toggle switch reset actuator, it allows for easy manual resetting after tripping. The instantaneous break time characteristic ensures rapid fault clearing, preventing damage to circuits and connected equipment. The Type C tripping curve is particularly suited for circuits with moderate inrush currents such as motors and transformers, reducing nuisance tripping.

The device provides a breaking capacity of 10 kA, ensuring effective fault isolation under high fault current conditions. Its IP20 rating denotes protection against solid objects larger than 12mm, making it ideal for indoor electrical environments.

Applications include residential electrical systems, automation control panels, machinery circuit protection, and other industrial settings requiring dependable overload and short circuit safety. This model is part of Eaton's xEffect FAZ series, known for quality and reliability. The product is manufactured in Romania in accordance with IEC and EN standards.

Designed for 1-pole plus neutral electrical protection. 2A rated current and 10 kA breaking capacity. Type C tripping characteristic for motor and transformer loads. Thermal-magnetic trip mechanism improves fault response.

Toggle switch allows easy reset after fault conditions. Compact form factor suitable for DIN rail mounting. Rated for 240V AC and 48V DC operation. IP20 ingress protection for indoor use. Manufactured in Romania with Eaton xEffect quality assurance.

Explore more high-quality Miniature Circuit Breakers and electrical protection devices in the Electronics & Electricals category at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model has a current rating of 2A, suitable for various electrical applications.

It is rated for 240V AC and 48V DC applications, making it versatile for different electrical systems.

The breaking capacity of this miniature circuit breaker is 10 kA, ensuring effective fault isolation under high fault current conditions.

It features Type C tripping characteristics, which are ideal for circuits with moderate inrush currents such as motors and transformers.

This unit is designed for DIN rail mounting, which facilitates easy installation in control panels and switchboards.

The dimensions of this model are 80mm in depth and 66mm in width, making it compact for electrical installations.

It is equipped with a toggle switch reset actuator, allowing for easy manual resetting after tripping.

This model has an IP20 protection rating, which means it is suitable for indoor electrical environments.

It utilizes a thermal-magnetic trip mechanism that provides protection against both overloads and short circuits.

This miniature circuit breaker is manufactured in Romania, adhering to IEC and EN standards.

It is suitable for residential electrical systems, automation control panels, and industrial settings requiring reliable overload and short circuit protection.

The instantaneous break time characteristic allows for rapid fault clearing, which helps prevent damage to circuits and connected equipment.
