SMC 320 mm Pneumatic Piston Rod Cylinder Double Acting Basic Mount with Air Cushion CP96
Specifications
| Country of Origin | China |
|---|---|
| Brand | SMC |
| Body Material | Carbon Steel, Steel, Die Cast Aluminium, Nitrile Rubber (NBR), Urethane, Aluminium Alloy, Resin, Bearing Alloy |
| Length | 538mm |
| Model | CP96 |
| Mount Type | Basic |
| Series | CP96 |
| Maximum Operating Temperature | +70°C |
| Stroke Length | 320mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Standards/Approvals | 4414 |
| Cushioning Type | Air Cushion |
| Piston Rod Gender | Male |
| Piston Rod Thread Standard | Metric |
| Piston Rod Thread Size | M20 x 1.5 |
Key Features
- Double acting cylinder delivers bidirectional controlled motion for versatile pneumatic applications.
- Basic mount type allows simple and secure installation.
- Air cushion mechanism reduces impact and extends service life.
- Carbon steel and aluminium alloy body ensures strength and durability.
- Male piston rod with M20 x 1.5 metric thread facilitates easy mounting.
- Supports maximum piston speed up to 1000 mm/s for fast cycle operation.
- Operates safely up to +70°C in moderate industrial environments.
- Complies with ISO 15552 standards for interchangeability and modularity.
Product Description
SMC CP96 Pneumatic Piston Rod Cylinder model CP96SDB80-320C features a 320 mm stroke length and total length of 538 mm, designed for industrial pneumatic systems requiring precise linear movement.
This double acting cylinder converts compressed air into controlled bidirectional motion, making it suitable for diverse automation tasks including pick-and-place actuators, press and clamp sequencing, valve positioning, and material handling grippers.
Constructed from a blend of carbon steel, steel, die-cast aluminium, nitrile rubber (NBR), urethane, aluminium alloy, resin, and bearing alloy, it balances mechanical strength with abrasion resistance and reduced wear.
Its male piston rod with M20 x 1.5 metric thread supports straightforward attachment to fixtures or tooling. The basic mount type further simplifies installation in pneumatic circuits.
The integrated air cushion cushioning type reduces end-of-stroke impact forces, thus extending the component's lifespan and enhancing smooth operation. It supports piston speeds up to 1000 mm/s and withstands operating temperatures up to +70°C.
The actuator complies with ISO 15552 dimensional and mechanical standards, ensuring interoperability with similar pneumatic cylinders and components. Double acting operation delivers bidirectional controlled motion. Basic mount type enables easy installation.
Air cushioning enhances durability and operational smoothness. Robust construction with multiple metal and polymer materials. Male piston rod with metric M20 x 1.5 thread for mounting ease. High piston speed capacity supports fast cycling.
Rated for operation up to +70°C in moderate temperature environments. Meets ISO 15552 standards for compatibility. This pneumatic piston rod cylinder is ideal for industrial automation, including manufacturing assembly lines, material handling, HVAC systems, and pneumatic controls.
Explore more pneumatic cylinder models and accessories on EnvMart.
Explore more products in our Pneumatic Piston Rod Cylinders category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The stroke length of this model is 320 mm.
It can operate safely up to +70°C in moderate industrial environments.
The body is made from a combination of carbon steel, steel, die-cast aluminium, nitrile rubber (NBR), urethane, aluminium alloy, resin, and bearing alloy.
It features an air cushion mechanism that reduces impact forces at the end of the stroke, enhancing operational smoothness and extending service life.
The total length of this cylinder is 538 mm.
The piston rod has a male thread size of M20 x 1.5 metric.
This model operates as a double acting cylinder, providing bidirectional controlled motion.
It supports a maximum piston speed of up to 1000 mm/s for fast cycle operation.
It uses a basic mount type, allowing for simple and secure installation.
It complies with ISO 15552 standards, ensuring interchangeability and modularity with similar components.
It is suitable for various automation tasks, including pick-and-place actuators, press and clamp sequencing, valve positioning, and material handling grippers.
The piston rod is male, facilitating easy mounting to fixtures or tooling.
