TE Connectivity MTA-100 Series Right Angle Through Hole Pin Header, 5 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 640455-5
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 5A |
| Model | 640455-5 |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Copper Alloy |
| Series | MTA-100 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.56mm |
| Mating Pin Length | 7.49mm |
Key Features
- The MTA-100 series facilitates cost-effective mass termination of wires when used with IDC connectors.
- Features glass filled polyester housing for enhanced durability and reliability.
- Rated for 5A current and 250V voltage with wide temperature operation from -55°C to 105°C.
- Polarized housings ensure accurate mating and prevent misalignment during assembly.
- Suitable for use in automotive, computer, and consumer electronics for wire-to-board connections.
- Contact material is copper alloy with tin plating to ensure excellent conductivity and solderability.
- Right angle mounting style ideal for space-constrained PCB layouts.
- Through hole mount type provides secure and stable connection on printed circuit boards.
Product Description
TE Connectivity 640455-5 MTA-100 Series Right Angle Through Hole Pin Header provides a robust PCB connector solution featuring 5 contacts with a 2.54 mm pitch and unshrouded housing. Designed for wire-to-board applications, this header enables quick and cost-saving mass termination when used with MTA-100 IDC connectors. The right angle orientation and through hole mounting ensure secure attachment to PCBs, supporting reliable performance in various industrial sectors.
The pin header's glass filled polyester housing offers excellent mechanical strength and thermal stability across a wide operating temperature range from -55°C to 105°C. The connector is rated for 5A current and 250V voltage, making it suitable for numerous electrical and electronic applications, including automotive body and chassis systems, driver information systems, and safety/security circuits.
The male copper alloy contacts plated with tin provide excellent electrical conductivity and solderability, ensuring consistent connections. The housing incorporates polarization notches to prevent mis-mating and is end-to-end stackable for flexible assembly configurations. The tail pin length of 3.56 mm and mating pin length of 7.49 mm are optimized for reliable contact engagement.
This unshrouded pin header design allows for easy visual inspection and maintenance access, making it a versatile choice for manufacturing environments that require dependable and economical wire termination solutions. It is widely used in automotive, computer, consumer electronics, and industrial equipment PCB assemblies.
The MTA-100 connector system uses insulation displacement contact technology for efficient wire termination. Polarized and stackable housing design simplifies wiring and prevents connection errors. Suitable for 28 AWG to 22 AWG discrete wire or ribbon cables.
Reliable right angle pin header for low-profile PCB designs. Ideal for mass termination in automotive, computing, and general electronics industries.
Choose the TE Connectivity 640455-5 MTA-100 series right angle pin header for proven quality and industrial-grade performance. Explore more PCB connector solutions in our Electronics Components category at EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 5A and a voltage of 250V.
It operates within a temperature range of -55°C to 105°C.
The pitch size of the contacts is 2.54 mm.
This pin header features 5 contacts.
The housing is made of glass filled polyester, and the contacts are copper alloy with tin plating.
It uses a through hole mounting type for secure attachment to printed circuit boards.
Yes, it is designed for cost-effective mass termination when used with IDC connectors.
The tail pin length is 3.56 mm.
Yes, it features polarized housings to ensure accurate mating and prevent misalignment during assembly.
It is suitable for automotive, computer, and consumer electronics applications for wire-to-board connections.
The mating pin length is 7.49 mm.
This model has 1 row of contacts.
