Schneider Electric Acti9 iCT Contactor 24V AC Coil 2-Pole 16A 1.3W 2 NO 250V AC

Schneider Electric A9C22112 Acti9 iCT Contactor is a 2-pole contactor designed for motor control applications using a 24V AC coil voltage and supporting a contact voltage of 250V AC. Rated at 16 amperes contact current with a low power consumption of 1.3 watts, it offers efficient and reliable operation in industrial automation and control systems.

This contactor features a compact design suitable for DIN rail mounting with dimensions of 81 mm width, 68 mm depth, and 18 mm length, facilitating easy panel integration. The contactor incorporates two normally open (NO) contacts and two auxiliary NO contacts, providing enhanced switching capabilities for complex control circuits.

Equipped with IP20 finger-safe screw terminals marked for both North American and International standards, the device prioritizes operator safety. Class-2 insulation ensures continuous safety for operators and unqualified personnel alike. The contactor operates reliably within a wide temperature range from -5°C to 60°C, making it suitable for various environmental conditions.

Manufactured in compliance with RoHS and IEC/EN 61095 standards, this device supports sustainable industry practices. The Acti9 iCT range is known for its durability, compactness, and ease of installation, making it ideal for controlling single-phase and three-phase motor loads in manufacturing, industrial automation, HVAC systems, and other commercial applications.

The high operational current rating of 16A and low power rating of 1.3W enable energy-efficient control, while the integrated auxiliary contacts expand application versatility. Schneider Electric’s Acti9 iCT contactors are designed to maintain excellent performance under continuous duty cycles, supporting long operating hours and demanding control requirements.

The product is part of Schneider Electric’s sustainable Better World initiative, emphasizing energy and carbon reduction through efficient components. This contactor is suitable for industrial, commercial, and automation control environments requiring reliable power switching and motor control.

Operates with a 24V AC coil voltage efficiently. Equipped with 2 NO (normally open) contacts for motor controlling functions. Supports a contact current rating of 16 amperes for moderate power loads. Compact DIN rail mount design measuring 81mm width by 68mm depth.

Incorporates IP20 finger-safe screw terminals enhancing user safety. Class-2 insulation offers continuous protection for operators and unqualified personnel. Wide operating temperature range from -5°C to 60°C ensures versatility.

Auxiliary configuration includes 2 NO contacts for additional switching capabilities. Conforms to RoHS and IEC/EN 61095 standards for quality and safety. Efficient power rating of 1.3W ensures low energy consumption. Explore Schneider Electric's range of Contactors and control gear at EnvMart for optimized industrial automation solutions.
