ITT Cannon MDM 37 Way Straight 1.27 mm Pitch Micro-D Cable D-Sub Connector MDM-37PH003B-A174
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | ITT Cannon |
| Orientation | Straight |
| Current | 3A |
| Model | MDM-37PH003B-A174 |
| Mount Type | Cable |
| Housing Material | Aluminium Alloy |
| Contact Material | Copper Alloy |
| Series | MDM |
| Termination Type | Pre-Wired |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 37 |
| Contact Gender | Male |
| Contact Size | 8 |
| Part Numbers | MDM-xxxSB-xxx have solder pot terminations that accept 26AWG max harness wire |
| ITT Cannon MDM 37 Way Straight 1.27 mm Pitch Panel Mount D-Sub ConnectorBrand | ITT Cannon |
Key Features
- Features 37 copper alloy contacts with gold plating for reliable conductivity.
- Aluminium alloy housing with electroless nickel plating for strong EMI and RFI shielding.
- Supports a maximum current of 3A with a pitch of 1.27 mm.
- Operating temperature range from -55°C to 125°C for harsh environments.
- Pre-wired termination with male contact gender for easy installation.
- Incorporates silicone elastomer compression seals for moisture and humidity resistance.
- Compatible with MIL-W-16878/4 Teflon insulated wires with 26AWG max harness wire capacity.
- Contacts are size 8 MICROPIN™ configured for high-density industrial use.
Product Description
ITT Cannon MDM-37PH003B-A174 is a 37 Way Straight Micro-D Cable D-Sub Connector featuring a 1.27 mm pitch, engineered for demanding industrial, military, and commercial interfaces.
This connector incorporates a lightweight yet rugged aluminium alloy housing with electroless nickel plating, providing excellent strength and shielding against electromagnetic interference (EMI) and radio-frequency interference (RFI). The high-density copper alloy contacts, plated with gold, ensure optimal conductivity and corrosion resistance.
The connector supports a continuous current rating of 3A and operates reliably across a wide temperature range from -55°C to 125°C, making it suitable for harsh and variable environmental conditions. The silicone elastomer compression seal safeguards against moisture ingress between contacts and between contacts and the shell, safeguarding electrical integrity.
Termination type is pre-wired with male contacts, using size 8 MICROPIN™ contacts designed to interface seamlessly with MIL-W-16878/4 color-coded Teflon wires up to 26AWG, enabling robust harness assemblies. Mounting is tailored for cable applications with straight orientation and included 2.31 mm mounting holes.
These connectors are widely used in military, industrial automation, aerospace, and commercial computing for reliable signal and power connections in compact high-density spaces. Features 37 copper alloy contacts with gold plating for reliable conductivity.
Aluminium alloy housing with electroless nickel plating for strong EMI and RFI shielding. Supports a maximum current of 3A with a pitch of 1.27 mm. Operating temperature range from -55°C to 125°C for harsh environments. Pre-wired termination with male contact gender for easy installation.
Incorporates silicone elastomer compression seals for moisture and humidity resistance. Compatible with MIL-W-16878/4 Teflon insulated wires with 26AWG max harness wire capacity. Contacts are size 8 MICROPIN™ configured for high-density industrial use.
Set contains one ITT Cannon MDM 37 Way Straight 1.27 mm Pitch Cable D-Sub Connector MDM-37PH003B-A174. Explore more connectors and electronic components at EnvMart for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 3A.
It operates reliably within a temperature range of -55°C to 125°C.
The connector features 37 contacts.
The housing is made of aluminium alloy, while the contacts are copper alloy with gold plating for conductivity.
It features a pre-wired termination with male contacts.
The pitch size is 1.27 mm.
Yes, it is designed to operate in harsh environments due to its wide temperature range and moisture resistance features.
It is compatible with MIL-W-16878/4 Teflon insulated wires with a maximum harness wire capacity of 26AWG.
This connector has a straight orientation.
The contacts are size 8 MICROPIN™ configured for high-density use.
The aluminium alloy housing features electroless nickel plating for strong EMI and RFI shielding.
It is widely used in military, industrial automation, aerospace, and commercial computing applications.
