SMC Pneumatic Guided Cylinder 25mm Bore, MGP Series, 30mm Stroke, Double Acting MGPM25TF-30Z

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Guided Cylinder 25mm Bore, MGP Series, 30mm Stroke, Double Acting MGPM25TF-30Z



Category Pneumatic Guided Cylinder Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Maximum Operating Pressure	1 Mpa
Height	58mm
Length	83.5mm
Model	MGPM25TF-30Z
Gross Weight	1.1kg
Width	26mm
Series	MGP
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-10°C
Stroke Length	30mm
Bore Diameter	25mm
Rod Type	Single
Action Type	Double Acting
Cushioning Type	Rubber Cushioning at Both Ends
Guide Type	Slide Bearing
Maximum Piston Speed	500 mm/s
Piston Rod Thread Standard	G

Key Features

Equipped with rubber cushioning at both ends to reduce impact and noise.
Maximum operating pressure rated at 1 MPa ensuring reliable performance.
Operates efficiently within temperature ranges from -10°C to 60°C.
Slide bearing guide provides enhanced lateral stability under side loads.
Supports piston speeds up to 500 mm/s suitable for high-cycle tasks.
Compact design with dimensions 83.5mm (length) x 26mm (width) x 58mm (height).
Lightweight unit weighing approximately 1.1 kg for easy mounting and handling.
Single rod type with G thread standard for mounting compatibility.

Product Description

SMC MGPM25TF-30Z Pneumatic Guided Cylinder is a compact, high-quality automation component designed for industrial linear motion applications. Featuring a 25mm bore and a 30mm stroke, this double acting cylinder offers controlled push and pull pneumatic actuation, ideal for precise position control and guided thrust tasks.

Designed with rubber cushioning at both ends, it reduces impact noise while preserving component longevity. The slide bearing guide enhances lateral stability against side loads, ensuring smooth, consistent operation across varied mechanical systems. This guided cylinder operates under a maximum pressure of 1 MPa and piston speeds up to 500 mm/s, making it suitable for high-cycle automated assembly and manufacturing environments.

The device performs optimally between -10°C and 60°C, accommodating typical industrial indoor conditions. Its compact dimensions (83.5mm length, 26mm width, 58mm height) and lightweight construction (1.1 kg) facilitate integration into robotic tooling, electrical panel production, and various pick-and-place mechanisms requiring precise linear actuation.

Rubber cushioning at both ends minimizes noise and impact. Rated for maximum operating pressure of 1 MPa. Supports piston speeds up to 500 mm/s for high-cycle applications. Slide bearing guide ensures reliable lateral stability.

Double acting operation enables precise push and pull movements. Operates efficiently within -10°C to 60°C temperature range. Single rod with G thread standard for versatile mounting. Compact and lightweight design for easy installation.

This product is extensively used in industrial automation including assembly line pick-and-place, electronics manufacturing, test rig positioning, and electrical panel tool actuation. It is engineered to deliver consistent performance and long service life under demanding operational conditions.

Explore more in the Pneumatic Guided Cylinders category at EnvMart for reliable automation components and systems.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum operating pressure of this model is rated at 1 MPa.

This unit features a stroke length of 30mm.

The bore diameter of this cylinder is 25mm.

The dimensions of this model are 83.5mm in length, 26mm in width, and 58mm in height.

It weighs approximately 1.1 kg, making it lightweight for easy handling.

This cylinder operates efficiently within a temperature range of -10°C to 60°C.

It is equipped with rubber cushioning at both ends to reduce impact and noise.

This model supports maximum piston speeds of up to 500 mm/s.

It features a single rod type with a G thread standard for mounting compatibility.

It utilizes a slide bearing guide, which provides enhanced lateral stability under side loads.

This cylinder is extensively used in industrial automation applications such as assembly line pick-and-place, electronics manufacturing, and test rig positioning.

This model is part of the MGP series of pneumatic guided cylinders.
