HARWIN M20 Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded, Brass Tin M20-9980646
Specifications
| Country of Origin | India |
|---|---|
| Brand | HARWIN |
| Orientation | Straight |
| Current | 3A |
| Model | M20-9980646 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | M20 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6.1mm |
Key Features
- This pin header features a dual-row, unshrouded configuration suitable for board-to-board and wire-to-board connections.
- Constructed with brass contacts and tin plating for reliable conductivity and corrosion resistance.
- The housing is made from high-temperature nylon suitable for reflow soldering.
- It supports a current rating of 3A and temperature range of -40°C to 105°C.
- The termination type is solder with a straight orientation, compatible with through hole mount PCB design.
- Tail pin length is 3 mm, mating pin length is 6.1 mm for effective connectivity.
- Widely used in embedded PCs, motherboards, consumer electronics, communications, industrial monitoring, and control applications.
Product Description
HARWIN M20-9980646 Straight Through Hole Pin Header is a high-quality PCB connector designed with 12 contacts arranged in two rows with a 2.54 mm pitch. Featuring an unshrouded, straight orientation, this connector is built for reliable board-to-board and wire-to-board connections.
The connector housing is made of durable nylon thermoplastic that withstands high temperatures up to 105°C, suitable for reflow soldering processes. Brass contacts with tin plating provide excellent electrical conductivity and corrosion resistance, ensuring long-lasting performance in demanding industrial and electronic applications.
This pin header supports a current rating of 3A and operates efficiently over a temperature range of -40°C to 105°C. The termination type is solder, making it suitable for through-hole PCB mounting. Tail pin length measures 3 mm while the mating pin length is 6.1 mm.
Designed with multiple configuration options, the M20 series offers flexibility for various applications including consumer electronics, embedded systems, communications equipment, industrial monitoring, and control systems. Its robust design ensures reliable signal integrity and mechanical stability.
This pin header features a dual-row, unshrouded configuration suitable for board-to-board and wire-to-board connections. Constructed with brass contacts and tin plating for reliable conductivity and corrosion resistance.
The housing is made from high-temperature nylon suitable for reflow soldering. It supports a current rating of 3A and temperature range of -40°C to 105°C. The termination type is solder with a straight orientation, compatible with through hole mount PCB design.
Tail pin length is 3 mm, mating pin length is 6.1 mm for effective connectivity. Widely used in embedded PCs, motherboards, consumer electronics, communications, industrial monitoring, and control applications.
These PCB Pin Headers ensure design flexibility and durability essential in modern electronics manufacturing. Incorporating the M20-9980646 enhances connectivity and system reliability in diverse industrial and commercial environments.
Explore more in EnvMart’s Electronics Components category for premium PCB connectors and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header supports a current rating of 3A.
The contacts in this model are arranged with a pitch of 2.54 mm.
It operates efficiently over a temperature range of -40°C to 105°C.
The housing is made from nylon, while the contacts are constructed from brass with tin plating.
This pin header has a total of 12 contacts.
This connector is designed for through hole mounting on PCBs.
The tail pin length measures 3 mm.
The mating pin length is 6.1 mm.
It uses a solder termination type, suitable for PCB mounting.
This model features an unshrouded configuration.
It is widely used in embedded PCs, motherboards, consumer electronics, communications, and industrial monitoring applications.
It supports both board-to-board and wire-to-board connection systems.
