MEAN WELL IP65 1 Output Dimmable Constant Voltage LED Driver 12V 120W 10A Potentiometer

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP65 1 Output Dimmable Constant Voltage LED Driver 12V 120W 10A Potentiometer

Name: MEAN WELL IP65 1 Output Dimmable Constant Voltage LED Driver 12V 120W 10A Potentiometer
Brand: MEAN WELL
SKU: 129108



Category LED Drivers Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP65
IP Rating	IP65
Mount Type	Screw
Series	HLG-120H
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	120W
Input Voltage	264, 90, 127, 370V ac
Output Voltage	12V
Power Dissipation	120W
Standards/Approvals	UL, EN, TUV
Dimming Operation	Potentiometer
Primary Type	AC-AC
Driver Current	10A

Key Features

Designed with IP65 rating for waterproof and dustproof protection.
Universal AC input voltage range compatible from 90 to 370V AC.
Supports three-in-one dimming including 1-10V DC, PWM signal, or resistance.
Built-in active power factor correction for high efficiency up to 94%.
Includes multiple protective features such as short circuit, overload, overvoltage, and overtemperature protection.
Suitable for indoor and outdoor LED lighting and street lighting applications.
Enclosed design with screw mount for secure installation.
Compliance with UL8750, EN61347, TUV, and other international safety standards.

Product Description

MEAN WELL HLG-120H-12A LED driver is a high-performance dimmable constant voltage LED driver rated for 120W power output and 12V voltage with 10A driver current. It features an IP65 waterproof design ideal for both indoor and outdoor installations in industrial, commercial, street lighting, and general LED lighting applications. The universal AC input supports voltage ranges between 90 to 370V AC ensuring flexible power compatibility.

This driver incorporates a built-in active power factor correction (PFC) function which enhances energy efficiency up to 94%. It supports a three-in-one dimming function controlled via potentiometer, allowing adjustment using 1-10V DC, PWM, or resistance signals. Built-in protections including short circuit, overload, overvoltage, and overtemperature guarantee enhanced reliability and safety.

The unit has a screw mount enclosure providing secure and robust installation. It complies with major international standards including UL8750, EN61347-1 and -2-13, and TUV certifications. The driver can operate efficiently in dry, damp, and wet environments, making it suitable for a wide range of industrial, laboratory, commercial, manufacturing, HVAC, and water treatment lighting solutions.

IP65 rated enclosure protects against water and dust ingress for outdoor use. Universal AC input from 90 to 370V supports global voltage variations. Efficient active PFC improves power factor and reduces harmonic distortion.

Flexible potentiometer-based dimming with multiple control methods. Multiple protections for enhanced device and load safety. Compliant with international safety and EMC standards ensuring reliability. Enclosed design with screw mounting for stable installation.

Ideal for industrial, street, commercial, HVAC, and general LED lighting applications.

This MEAN WELL IP65 LED driver enhances lighting system performance while ensuring safety and compliance with industry standards. Explore the full range of LED Drivers and lighting components available for industrial and commercial applications on EnvMart.
