binder Circular Connector Panel Mount 16 Contacts Socket Male M16 IP40 680 Series 09-0339-00-16
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 60V |
| Brand | binder |
| Orientation | Straight |
| Current | 3A |
| IP Rating | IP40 |
| Mount Type | Panel Mount |
| Housing Material | Metal |
| Contact Material | Brass |
| Series | 680 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shell Size | 20 |
| Mating Type | Screw-On |
| Connector Size | M16 |
| Plug/Socket | Socket |
Key Features
- Designed for robust and miniature panel mounting applications.
- Operates at 60V and 3A for electrical reliability.
- Gold-plated brass contacts prevent oxidation.
- Solder termination and straight orientation for easy installation.
- Suitable for medical equipment and industrial automation.
- Metal housing withstands -40°C to 85°C operating temperatures.
- Screw-on mating type with shell size 20 provides secure connection.
- Part of binder’s reliable 680 Series connectors.
Product Description
binder 09-0339-00-16 circular connector is a high-quality panel mount socket connector with 16 contacts, designed to provide reliable electrical connections for industrial and medical equipment applications. This M16 sized connector features a straight body with metal housing, ensuring durability and robust performance in demanding environments.
Operating at 60 volts and 3 amperes, it is ideal for use in machine tool control systems, industrial automation, and instrumentation. The connector employs gold-plated brass contacts that prevent oxidation and enhance conductivity, promoting long-term reliability. Termination is solder type, simplifying the installation process for technicians.
Its IP40 rating protects against solid objects greater than 1 mm, suitable for panel mounting with screw-on mating type and shell size 20. The connector withstands an operating temperature range from -40°C to +85°C, making it capable of enduring varying industrial conditions.
The binder 680 Series is known for miniature yet rugged designs that facilitate easy assembly without compromising durability. Its straight orientation and male contact gender socket configuration make it a dependable choice for demanding industrial environments.
Key features include metal housing for enhanced protection, gold contact plating for extended lifespan, and compatibility with a range of termination methods. This product is manufactured in Germany to the highest standards and is supplied in new condition.
Designed for robust and miniature panel mounting applications. Operates at 60V and 3A for electrical reliability. Gold-plated brass contacts prevent oxidation. Solder termination and straight orientation for easy installation.
Suitable for medical equipment and industrial automation. Metal housing withstands -40°C to 85°C operating temperatures. Screw-on mating type with shell size 20 provides secure connection. Part of binder’s reliable 680 Series connectors.
Explore the binder range and related Circular Connectors at EnvMart for advanced industrial electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates at 60 volts and 3 amperes, ensuring reliable electrical connections for various applications.
It has an IP40 rating, which protects against solid objects greater than 1 mm, making it suitable for panel mounting applications.
The connector can withstand operating temperatures ranging from -40°C to +85°C, suitable for demanding industrial environments.
This connector features 16 contacts, providing multiple connection points for electrical reliability.
It employs a solder termination type, which simplifies the installation process for technicians.
The contacts are made of brass and are gold-plated to prevent oxidation and enhance conductivity.
It features a metal housing, which provides enhanced protection and durability.
The shell size of this model is 20, which is compatible with screw-on mating types for secure connections.
This model has a straight orientation, which aids in installation and connection.
It is manufactured in Germany, adhering to high-quality standards.
It is suitable for use in medical equipment and industrial automation, providing reliable connections in these fields.
This model is classified as a panel mount socket connector with a male contact gender.
