TE Connectivity Dynamic 5000 Series Straight Through Hole PCB Header, 4 Contacts, 10.16 mm Pitch, 1 Row, Shrouded 1-917542-2
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 630V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 15A |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Copper Alloy |
| Series | Dynamic 5000 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 10.16mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Supports a current rating of 15A for reliable power transmission.
- Constructed with glass filled polyester housing for durability.
- Designed with a single row orientation for compact board mounting.
- Contact plating is gold with copper alloy contacts to ensure low resistance.
- Mounts through hole with solder termination for robust PCB connection.
- Operates reliably within -55°C to 105°C temperature range.
- Rated for voltage up to 630V for various electrical applications.
- Male contact gender suitable for wire-to-board connections.
Product Description
TE Connectivity 1-917542-2 Dynamic 5000 Series Straight Through Hole PCB Header offers a robust and durable solution for electronic assemblies requiring a reliable wire-to-board connection. This PCB header is designed with a single row of 4 male contacts spaced at 10.16 mm pitch, suitable for various power and signal transfer applications.
The housing is made of glass filled polyester, providing excellent mechanical strength and resistance to environmental factors. Contacts are fashioned from copper alloy and plated with gold to ensure superior conductivity and corrosion resistance. The connector features a shrouded design for enhanced protection against damage and dust ingress.
This header supports a current rating of 15A and a voltage rating of 630V, making it suitable for demanding electrical environments. Its through hole mount type with solder termination offers stable and secure PCB installation, designed for PCB thicknesses between 1.6 to 2.4 mm. Operating temperature range from -55°C to 105°C accommodates both industrial and commercial applications.
Ideal for use in electronic component manufacturing, power distribution, industrial machinery, and embedded systems, the TE Connectivity Dynamic 5000 Series provides reliable electrical connectivity and endurance.
Supports a current rating of 15A for reliable power transmission. Constructed with glass filled polyester housing for durability. Designed with a single row orientation for compact board mounting. Contact plating is gold with copper alloy contacts to ensure low resistance.
Mounts through hole with solder termination for robust PCB connection. Operates reliably within -55°C to 105°C temperature range. Rated for voltage up to 630V for various electrical applications. Male contact gender suitable for wire-to-board connections.
Shrouded design provides protection and reliable mating. Explore the TE Connectivity PCB Headers category on EnvMart for a wide selection of connectors tailored for industrial, commercial, and electronic manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 15A, making it suitable for reliable power transmission.
It is rated for a voltage of up to 630V, which allows for various electrical applications.
The housing is constructed from glass filled polyester, while the contacts are made of copper alloy and plated with gold for low resistance.
It operates reliably within a temperature range of -55°C to 105°C, accommodating both industrial and commercial applications.
This model features 4 male contacts arranged in a single row.
The contact pitch is 10.16 mm, which is standard for this type of PCB header.
Yes, it mounts through hole with solder termination, providing a stable and secure connection to the PCB.
It utilizes a wire-to-board connector system, suitable for reliable electrical connectivity.
The contacts are male, which is suitable for wire-to-board connections.
The shrouded design provides enhanced protection against damage and dust ingress, ensuring reliable mating.
The country of origin for this model is India.
It features a solder termination type, which is common for through hole connectors.
