Amphenol Communications Solutions 25 Way Straight 2.76 mm Pitch Panel Mount D-Sub Connector Female FCE17

Amphenol Communications Solutions FCE17 25 Way Straight 2.76 mm Pitch Panel Mount D-Sub Connector Female is designed for high-reliability panel mounting and seamless integration in electronic assemblies. With a steel housing and gold over nickel plated phosphor bronze contacts, this connector offers superior durability and excellent electrical performance suitable for demanding industrial and electronic applications.

Operating at 300 volts and supporting a current of up to 5 amperes, it covers a broad range of power connector needs. The connector’s pitch of 2.76 mm and 25 contact points provide precise and stable connections, accommodating wires up to 20 AWG via solder bucket termination with matte tin plating.

This model belongs to the FCE17 series of filtered D-Sub Connectors, which integrate capacitors inside the connector between contacts and the shell for better EMI control. The capacitors effectively suppress unwanted electromagnetic interference, providing enhanced EMC compliance and immunity which is critical in industrial, telecommunications, and computing environments.

The panel mount design includes Ø3 mm mounting holes with fixing centers specific to the size B25, facilitating easy and secure installation. The connector supports operating temperatures ranging from -40°C to 85°C, ensuring reliability across a wide range of environmental conditions.

Use cases for this connector include applications in industrial control systems, data communications, and instrumentation where EMI suppression and robust mechanical connections are essential. The integrated filtering elements reduce the need for additional PCB components, simplifying circuit design and reducing cost.

Equipped with 25 contacts for versatile connectivity. Supports a current rating of 5 amperes. Features a straight orientation and panel mount configuration. Constructed with a steel housing for durability. Operates safely up to 300 volts with a temperature range from -40°C to 85°C.

Uses phosphor bronze contacts plated with gold over nickel for corrosion resistance. Offers a pitch spacing of 2.76 mm ensuring precise connection. Solder termination type with matte tin plating accommodates wire up to 20 AWG.

Provides EMI filtering with integrated capacitors for improved electromagnetic compatibility. Explore our wide range of industrial and electronic connectors at EnvMart to find the perfect solutions for your application requirements.
