Phoenix Contact 3-Contact 3.5 mm Pitch 1 Row Pluggable Terminal Block 400V Polyamide Housing PTDA 1.5/3-PH-3.5 1725120
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 400V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Right Angle |
| Current | 10A |
| Length | 10.5mm |
| Model | 1725120 |
| Depth | 16mm |
| Width | 20mm |
| Housing Material | Polyamide |
| Series | PTDA 1.5/3-PH-3.5 |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 3 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Push-in Spring |
Key Features
- Constructed with durable polyamide housing for insulation and sturdiness.
- Push-in spring wire connection method for secure and easy wiring.
- Right angle orientation suitable for compact PCB layouts.
- Supports wire sizes from 0.2 mm² to 1.5 mm² (24 AWG to 16 AWG).
- Designed for currents up to 10 A ensuring safe electrical handling.
- Green color coding for easy identification in assemblies.
- Single row configuration optimizes PCB space usage.
- Series PTDA 1.5/3-PH-3.5 known for modular pluggable solutions.
Product Description
Phoenix Contact 1725120 is a high-quality pluggable terminal block designed for electronic and electrical applications requiring robust and reliable connections. This 3-contact terminal block features a 3.5 mm pitch and supports a maximum voltage of 400 volts, making it suitable for moderate power electronic circuits in industrial controls and automation.
The terminal block is constructed with polyamide housing, which provides excellent insulation and mechanical stability. It employs a push-in spring wire connection method, facilitating a secure and tool-free connection while reducing wiring time. Its right angle orientation allows for neat and compact circuit board layouts.
This model supports wire sizes ranging from 0.2 mm² to 1.5 mm² (24 AWG to 16 AWG) and can handle currents up to 10 amperes, ensuring safety and compliance with electrical standards. The unit's dimensions are 20 mm width, 16 mm depth, and 10.5 mm length, fitting efficiently into electronic assemblies.
The terminal block is green-colored, aiding visual identification on printed circuit boards. It belongs to the PTDA 1.5/3-PH-3.5 series, which is known for versatile, modular, and pluggable connection systems compatible with a range of PCB applications.
Durable polyamide housing for electrical insulation and mechanical strength. Push-in spring connection ensures quick and secure wiring. Right angle design ideal for space-saving PCB installation. Supports standard wire sizes from 0.2 to 1.5 mm² (24 AWG to 16 AWG).
Rated for 10 A current and 400 V voltage. Compact dimensions optimize PCB space utilization. Green color for easy system identification. Single-row, 3-contact configuration for versatile connections. Part of the trusted PTDA 1.5/3-PH-3.5 pluggable terminal block series.
This pluggable terminal block is ideal for use in industrial automation, control cabinets, power supplies, and electronics manufacturing, where reliable electrical connections are essential. Its modular design allows easy replacement and upgrade in complex electrical assemblies.
Explore more Pluggable Terminal Blocks and connectors to complement your electronic systems within the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block is rated for a maximum voltage of 400 volts, making it suitable for moderate power electronic circuits.
It can handle currents up to 10 amperes, ensuring safe electrical handling in various applications.
This model supports wire sizes ranging from 0.2 mm² to 1.5 mm² (24 AWG to 16 AWG).
The contacts in this terminal block have a pitch of 3.5 mm, allowing for compact PCB layouts.
It features a right angle orientation, which is suitable for space-saving installations on circuit boards.
The housing is constructed from polyamide, providing insulation and mechanical stability.
The dimensions of this model are 20 mm in width, 16 mm in depth, and 10.5 mm in length.
It employs a push-in spring wire connection method, which allows for secure and tool-free wiring.
This model is part of the PTDA 1.5/3-PH-3.5 series, known for its modular pluggable solutions.
The terminal block is green, which aids in visual identification during assembly and installation.
This terminal block features 3 contacts, allowing for versatile connections in electronic applications.
The country of origin for this terminal block is India.
