HARTING SEK 18 Series Straight Through Hole 2 Row Shrouded PCB Header 16 Contacts 2.54mm Pitch 1kV 1A 09185166927
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 1kV |
| Brand | HARTING |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | SEK 18 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- This PCB header features 16 gold-plated copper alloy contacts arranged in 2 rows for reliable conductivity.
- The housing is made of durable polybutylene terephthalate suitable for operation from -55°C to 125°C.
- The connector system supports through hole mounting and solder termination type.
- It supports a maximum operating voltage of 1 kV and current of 1 ampere.
- With a contact length of 15 mm and wrap post connectors, it optimizes PCB assembly.
- The product is made in Switzerland and supplied without ejectors, which are available separately.
Product Description
HARTING 09185166927 SEK 18 Series Straight Through Hole PCB Header is a high-quality shrouded male header designed for wire-to-board applications. It features 16 gold-plated copper alloy contacts arranged in two rows with a pitch of 2.54 mm, ensuring stable and efficient electrical connections suitable for industrial, electronic, and manufacturing uses.
The connector's housing is molded from polybutylene terephthalate, delivering excellent temperature resistance from -55°C up to 125°C, making it reliable under harsh environmental conditions. Its through hole mount type ensures a secure mechanical and electrical connection to PCBs.
Operating at a maximum rating of 1 kV voltage and 1 A current, this header is ideal for low power applications requiring robust connector performance and long-term durability. This product is supplied without ejectors, allowing customization with locking levers available under separate ordering codes.
Such headers are commonly used in industries including electronics manufacturing, telecommunication equipment, industrial controls, and prototype development. 16 gold-plated contacts arranged in 2 rows with 2.54 mm pitch.
Polybutylene terephthalate housing for high durability and temperature resistance. Through hole mounting and solder termination ensure solid PCB connections. Rated for 1 kV and 1 A operations suitable for various electronic devices.
Male contact gender with wrap post connectors and 15 mm contact length. Manufactured in Switzerland with compliance to IEC standards. Explore more about HARTING products and related PCB connectors on EnvMart for industrial and laboratory applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a maximum operating voltage of 1 kV and a maximum current of 1 ampere.
It features 16 gold-plated contacts arranged in 2 rows with a pitch of 2.54 mm.
The housing is made from polybutylene terephthalate, which provides excellent temperature resistance.
It operates within a temperature range of -55°C to 125°C.
This model supports through hole mounting and solder termination type.
This header has a male contact gender with wrap post connectors.
The product is supplied without ejectors, which are available separately.
This PCB header is manufactured in Switzerland.
It is commonly used in electronics manufacturing, telecommunication equipment, industrial controls, and prototype development.
The contact length of the connectors is 15 mm.
This model utilizes a wire-to-board connector system.
The contacts are made of gold-plated copper alloy for reliable conductivity.
