HARTING D-Sub 37 Way Right Angle Through Hole Connector 2.77 mm Pitch, Steel Housing, 4 to 40 UNC Threaded Insert 09684537612

HARTING 09684537612 is a high-quality D-Sub connector featuring a 37 way female contact configuration with a right angle orientation and a 2.77 mm pitch. Designed for through hole mounting, it is equipped with 4 to 40 UNC threaded inserts that ensure stable and secure installation on printed circuit boards.

The connector housing is manufactured from steel, providing excellent mechanical robustness and electromagnetic interference shielding required in demanding industrial, telecommunications, and computing applications. The copper alloy contacts offer high conductivity and excellent resistance to corrosion, maintaining reliable electrical performance.

This model supports a current rating of 6.5 amperes and is rated for operation up to 1 kV voltage, making it suitable for use in power and signal interface applications. Its operating temperature range from -55°C up to 125°C ensures dependable operation in harsh environmental conditions.

The connector complies with IEC 60807 standards, reflecting its adherence to recognized international quality measures. Its solder termination type is ideal for permanent, strong connections in electronics manufacturing and repair settings.

Typical use cases include industrial machinery, laboratory instrumentation, telecommunications equipment, and electronic control units, where reliable high-density multi-contact connectors are essential. This D-Sub connector supports efficient PCB layout with its right angle mounting style, helping to optimize space in compact assemblies.

Package includes the connector with threaded inserts and grounding board locks that provide additional mechanical and electrical integrity. This product is manufactured in China. Explore more connectors and accessories under the Electronics & Electricals category at EnvMart to find compatible solutions for your electronic assembly needs.

Features 37 female contacts suitable for high-density applications. Supports current rating of 6.5A ensuring robust electrical performance. Orientation is right angle facilitating PCB mounting space optimization. Includes 4 to 40 UNC threaded insert mounting hardware for secure fixing.

Operates within -55°C to 125°C temperature range for versatile industrial use. Constructed with copper alloy contacts to enhance conductivity and corrosion resistance. Certified to IEC 60807 standard ensuring compliance and quality assurance.

Voltage rating of 1kV suitable for a wide range of electronic systems. Housing made of steel provides mechanical strength and EMI shielding. Termination by solder type for dependable connections in assembly processes. Discover a wide selection of power connectors, D-Sub Connectors, and components at EnvMart for your industrial, manufacturing, and laboratory applications.
