Schneider Electric Zelio Logic Series Logic Module, 6 Inputs, 4 Relay Outputs, 24V DC Supply, Ladder Logic SR2D101BD

Category Logic Module Brand Schneider Electric Condition New

Specifications

Country of Origin India
Brand Schneider Electric
Length 71.2mm
Model SR2D101BD
Depth 59.5mm
Width 107.6mm
Mount Type DIN Rail
Number of inputs 6
Output type Relay
Series Zelio Logic
Input Type Discrete
Maximum Operating Temperature 55°C
Minimum Operating Temperature -20°C
Number of outputs 4
Supply Voltage 24V dc
Standards/Approvals CSA, C-Tick, GL, GOST, UL
Programming Language Used Ladder Logic
Schneider Electric PLC Cable for Use with For smart relayBrand Schneider Electric
Basic zelio logic PLC,SR1D101BD 10i/oBrand Schneider Electric

Key Features

  • Operates on 24V DC supply voltage with DIN rail mount compatibility.
  • Wide operating temperature range from -20°C to 55°C for harsh environments.
  • Includes battery backup and a display for operation status.
  • Complies with CSA, C-Tick, GL, GOST, and UL standards.
  • Screw terminal connections provide secure and vibration-resistant wiring.
  • Supports simultaneous control of up to four relays.
  • Ideal for water pumps, irrigation systems, and packaging warehouses automation.
  • User-friendly ladder logic programming enables straightforward configuration.

Product Description

Schneider Electric SR2D101BD Zelio Logic Series Logic Module is a versatile programmable logic controller designed for simple automation applications requiring 6 discrete inputs and 4 relay outputs. It operates on a 24V DC supply voltage and supports ladder logic programming for intuitive setup and control.

The module features a compact form factor with dimensions of 71.2 mm (L) x 107.6 mm (W) x 59.5 mm (D), making it suitable for space-constrained installations. It includes a display for monitoring operational status and a battery backup to maintain memory during power interruptions.

Designed for reliability, the Logic Module offers a wide operating temperature range from -20°C to 55°C, allowing deployment in harsh environmental conditions. Screw terminal connections ensure a robust electrical connection resistant to vibration and mechanical stress. The unit complies with multiple international standards including CSA, C-Tick, GL, GOST, and UL for assured safety and quality.

Its ability to control up to four relays simultaneously makes it ideal for managing various industrial and commercial automation tasks such as water pumps, irrigation systems, and packaging warehouses. The ladder logic programming language is graphics-based, facilitating easy programming and configuration.

Applications include industrial automation, manufacturing process control, HVAC systems, agricultural irrigation management, and food and beverage production automation. Compact size suitable for DIN rail mounting and tight spaces.

Wide temperature range supports deployment in varied environments. Reliable relay output control for diverse automation needs. Battery backup preserves programming during power outages. Compliant with key international certifications.

User-friendly ladder logic programming enhances usability. Secure, vibration-resistant electrical connections. Explore more Schneider Electric automation solutions available at EnvMart for industrial and commercial control systems.

Schneider Electric Zelio Logic Series Logic Module, 6 Inputs, 4 Relay Outputs, 24V DC Supply, Ladder Logic SR2D101BD
Looking to purchase in bulk?
  • Purchase item in bulk quantity
  • Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model operates on a 24V DC supply voltage.

It features 6 discrete inputs and 4 relay outputs for control tasks.

The dimensions are 71.2 mm in length, 107.6 mm in width, and 59.5 mm in depth.

It can operate in temperatures ranging from -20°C to 55°C.

It uses ladder logic programming for configuration and control.

This unit is compatible with DIN rail mounting.

It complies with CSA, C-Tick, GL, GOST, and UL standards.

It features screw terminal connections for secure and vibration-resistant wiring.

It is ideal for applications such as water pumps, irrigation systems, and packaging warehouses automation.

Yes, it includes a battery backup to maintain memory during power interruptions.

It offers a display for monitoring operational status and easy ladder logic programming.

The output type is relay, allowing for control of various devices.
