Mitsubishi Electric FX3U Series Logic Module, 24-Input Sink Input, 24 Relay Outputs, 24V DC

Mitsubishi Electric FX3U-48MR/DS is a high-performance logic module designed for industrial automation systems. It features 24 sink-type inputs and 24 relay outputs rated for 8A, powered by a 24V DC supply. This logic module supports a program capacity of 64000 steps, enabling complex machine control sequences.

The module includes a battery backup system to retain program memory during power loss and offers multiple communication ports including RS232C, RS422, RS485, and USB, facilitating seamless integration with other devices. The unit operates reliably within an ambient temperature range from 0°C to 50°C and mounts easily on a DIN rail, making it suitable for compact control panel installations.

The device is programmed using Ladder Logic language, familiar to automation engineers, and supports networking standards such as PROFIBUS/DP and Ethernet, allowing it to be incorporated into sophisticated manufacturing and processing environments. For real-time process management, the module includes a built-in display and real-time clock, providing immediate feedback on operation status and scheduling capabilities.

Measuring 182mm in length, 90mm in width, and 86mm in depth, this Mitsubishi Electric module balances compact form factor with robust functionality. It meets international standards with UL and CE approvals and is manufactured in Japan, ensuring high quality and reliability.

Program capacity of 64000 steps for advanced control. Battery backup to prevent data loss during outages. Multiple communication ports for versatile connectivity. Operational temperature range of 0°C to 50°C for various environments.

Integrated display and real-time clock enhance monitoring and control. Relay outputs rated at 8A suitable for diverse automation tasks. DIN rail mounting for convenient panel integration. Compatible with PROFIBUS/DP and Ethernet networks.

Compact size optimized for space-constrained applications. UL and CE standards certified for safety and performance.

This Mitsubishi Electric FX3U Logic Module is suitable for diverse industrial applications including manufacturing automation, process control, and complex machinery operations. Its extensive connectivity options and programming flexibility make it ideal for integration in modern industrial automation systems. Explore more Mitsubishi Electric industrial automation products on EnvMart for reliable and efficient solutions.
