Eaton PXF-A Series Residual Current Circuit Breaker 25A 3+N-Pole 500 mA Type A 500A 400V AC 236775 PXF-25/4/05-A

Eaton 236775 PXF-25/4/05-A residual current circuit breaker is engineered to offer advanced electrical circuit protection in residential and commercial installations. This device provides reliable earth leakage protection with a 25 amp current rating and 3+N poles configuration, making it ideal for multi-pole systems operating at 400V AC.

The Type A tripping characteristic is designed to detect and react to alternating and pulsating direct currents, ensuring enhanced safety against electric shocks and electrical faults. With a trip sensitivity of 500 mA and instantaneous break time, it provides prompt interruption of electrical power upon fault detection.

This circuit breaker is designed with compact dimensions (80mm height x 70mm width x 70.5mm depth) and mounts easily on DIN rails, facilitating straightforward integration within electrical panels. Quick connect terminals simplify wiring, improving installation efficiency.

Compliant with international standards such as RoHS and IEC/EN 61008 and meeting DIN VDE 0664 part 10 requirements, it guarantees high quality and safety benchmarks. The device features fault current current-proofing up to 250 A and supports retrofittable auxiliary switches for expanded functionality.

The Eaton PXF-A series ensures protection from special non-smoothened DC fault currents with clear real contact position display and triggered state signaling through signal contacts, enhancing operational reliability and maintenance ease.

This Residual Current Circuit Breaker is essential for industrial, residential, and commercial electrical safety systems, preventing electrical hazards by cutting off power immediately upon detection of leakage currents or faults.

Designed for earth leakage protection in industrial and residential environments. Trip sensitivity of 500 mA for reliable fault detection. 3+N poles configuration suitable for complex electrical systems. Instantaneous break mechanism for swift protection response.

Compact and DIN rail mountable for panel integration. Complies with international electrical safety standards. Quick connect terminal type for efficient installation. Type A rated for alternating and pulsating direct current protection.
