KYOCERA AVX VC Varistor Surface Mount 1 A Clamping Voltage 32 V VC120614A300DP

KYOCERA AVX VC120614A300DP VC Varistor is a surface mount transient suppressor designed to protect sensitive electronic circuits by clamping voltage surges up to 32 V with a clamping current of 1 A. This device is ideal for use in industrial, electronics manufacturing, and power supply applications where surge protection is critical.

The multilayer ZnO ceramic construction provides exceptional reliability and performance for transient voltage suppression. Measuring 3.2 mm in length, 1.6 mm in depth, and 1.02 mm in height, this compact component fits efficiently on printed circuit boards using surface mount technology. It is engineered to operate safely at temperatures up to 125°C, ensuring durability in harsh environments.

This VC series varistor features a maximum surge current capacity of 40 A and energy rating of 0.1 joule, making it suitable for protecting against low energy transient surges. It supports a maximum AC voltage of 10 V AC and a maximum DC voltage of 14 V DC. The device's copper clad steel solder-coated leads ensure stable and reliable electrical connections.

Though it does not carry specific automotive approval, it is widely used in electronic component protection across various industrial applications. The varistor does not have formal standards or approvals but conforms to industry norms for surge protection devices.

The part is supplied ready for surface mounting in automated assembly lines, aiding in production efficiency and quality control. Typical use cases include circuit board protection in consumer electronics, industrial control systems, power supplies, and laboratory equipment.

The device offers a maximum surge current of 40 A to protect electronic circuits. It has a compact size of 3.2 mm length, 1.6 mm depth, and 1.02 mm height. Constructed from multilayer ZnO ceramic material ensuring high reliability.

Designed to operate reliably up to 125°C maximum temperature. Provides transient suppression for electronic components in surge protection applications. Features a surface mount type for efficient PCB assembly. Energy rating of 0.1 J suitable for low energy surge conditions.

Maximum AC voltage rating of 10 V AC and maximum DC voltage of 14 V DC. Finished with copper clad steel lead solder coating for enhanced connectivity. Compliant with general electronic standards but does not have specific approvals or automotive standards.
