Nuvotem Talema Toroidal Transformer 320 VA, 230 V ac ±24 V ac, 1 Output, Centre Tapped, SFB0320-230-24

The Nuvotem Talema SFB0320-230-24 Toroidal Transformer is a precision engineered device designed for use in control circuit applications and general industrial purposes. Its 320 VA power rating with a primary input voltage of 230 V AC and a secondary voltage output of ±24 V AC ensures reliable power conversion for a variety of electronic setups.

Featuring a centre tapped winding type, this toroidal transformer minimizes electromagnetic interference and noise, making it ideal for environments requiring stable and clean power distribution. The product is designed to operate efficiently within a frequency range of 50 Hz to 60 Hz and is suitable for temperatures ranging between 105°C to 180°C, assuring durability and consistent performance under demanding conditions.

Its compact chassis mount design, coupled with screw termination connections, facilitates straightforward installation and secure electrical contact. The physical dimensions include a height of 120 mm and a toroid centre size of 96 x 43 mm, making it a compact solution for space-constrained applications.

The transformer complies with stringent international standards including VDE0550, VDE0551, BS415, EN60065, EN60742, and EN60950 Class II safety classes, ensuring the highest levels of operational safety and quality assurance. This certification makes it suitable for a wide range of industrial, laboratory, HVAC, and manufacturing applications.

Its low radiated magnetic field and low induced hum enhance performance stability, especially in sensitive control panel installations where noise can be detrimental. The transformer’s zinc plated steel mounting bracket offers mechanical stability and corrosion resistance, fostering extended service life.

Key benefits include ease of installation, superior efficiency, and robust construction. The SFB series is known for quality manufacturing and rigorous testing in accordance with relevant industrial standards.

Operates at 230 V AC primary voltage and ±24 V AC secondary voltage. Power rating of 320 VA with a secondary current of 6.667 A. Centre tapped winding design reduces noise and electromagnetic interference. Vertical chassis mounting on a zinc plated steel bracket with screw terminals.

Certified to VDE0550, VDE0551, BS415, EN60065, EN60742, and EN60950 Class II standards. Compact form factor with dimensions 96 x 43 mm toroid centre and 120 mm height. Wide operating temperature range from 105°C to 180°C.

Designed for industrial, laboratory, HVAC, manufacturing, and general electronic applications. Explore and source high quality transformers like the Nuvotem Talema SFB0320-230-24 Toroidal Transformer from EnvMart for your specialized electrical component needs.
