Siemens Inverter Drive 5.5 kW 3 Phase SINAMICS G115D Series 480V 26.4 A 6SL3520-3XE45-5AF0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-3XE45-5AF0 |
| IP Rating | IP65, IP66 |
| Mount Type | Panel |
| Series | SINAMICS G115D |
| Overall Width | 380mm |
| Power Rating | 5.5kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 26.4A |
| Standards/Approvals | CE, C-Tick (RCM), EAC, KCC, REACH, SEMI F47 |
| Maximum Supply Voltage | 480V |
| Overall Depth | 129mm |
| Minimum Supply Voltage | 380V |
Key Features
- Designed for use with three-phase asynchronous or synchronous reluctance motors with IE3 or IE4 efficiency class.
- Supports output current up to 26.4 A with supply voltage range of 380V to 480V.
- Equipped with integrated safety features including STO function with fail-safe digital input F-DI or PROFIsafe.
- Panel mount type with IP65 and IP66 protection ratings ensuring robust industrial use.
- Operating temperature range from -30°C to 55°C suitable for harsh environments.
- Compact dimensions with overall width of 380 mm and depth of 129 mm for space-efficient installation.
- Compliance with international standards including CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47.
Product Description
Siemens 6SL3520-3XE45-5AF0 is a high-performance inverter drive from the SINAMICS G115D series, delivering a power rating of 5.5 kW. This 3 phase inverter drive is designed to provide reliable and efficient variable frequency control for industrial motors, catering to diverse automation and control applications.
The drive supports three-phase asynchronous motors with efficiency class IE3, as well as synchronous reluctance motors with efficiency class IE4, enhancing energy efficiency and reducing operational costs. With a maximum output current of 26.4 A and an output frequency up to 550 Hz, it offers precise speed control for complex industrial processes.
Mountable on panels, the product features an IP65 and IP66 rating, ensuring high resistance to dust and water ingress, ideal for harsh industrial environments. It operates effectively within a wide temperature range from -30°C to 55°C, accommodating challenging installation conditions.
Integrated safety functions, including STO with fail-safe digital inputs and PROFIsafe compatibility, provide enhanced operational safety. Its modular design eliminates the need for a control cabinet, simplifying installation and reducing cooling demands. Overall dimensions are 380 mm width and 129 mm depth, making it compact and space-saving.
This inverter drive complies with several international standards such as CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47, confirming its quality and reliability. Originating from the United Kingdom, it is suitable for industrial, manufacturing, automation, and HVAC applications requiring precise motor control.
Designed for use with three-phase asynchronous or synchronous reluctance motors with IE3 or IE4 efficiency class. Supports output current up to 26.4 A with supply voltage range of 380V to 480V. Equipped with integrated safety features including STO function with fail-safe digital input F-DI or PROFIsafe.
Panel mount type with IP65 and IP66 protection ratings ensuring robust industrial use. Operating temperature range from -30°C to 55°C suitable for harsh environments. Compact dimensions with overall width of 380 mm and depth of 129 mm for space-efficient installation.
Compliance with international standards including CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47. Explore more Siemens Inverter Drives and automation control gear in the EnvMart catalog for versatile industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inverter drive has a power rating of 5.5 kW.
It supports a maximum output current of 26.4 A.
The operating temperature range is from -30°C to 55°C.
It is designed for three-phase asynchronous motors with IE3 efficiency and synchronous reluctance motors with IE4 efficiency.
The inverter drive can operate at an output frequency of up to 550 Hz.
The overall dimensions are 380 mm in width and 129 mm in depth.
It supports panel mounting.
It has IP65 and IP66 protection ratings, ensuring resistance to dust and water ingress.
It complies with CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47 standards.
It includes integrated safety features such as the Safe Torque Off (STO) function with fail-safe digital inputs and PROFIsafe compatibility.
The supply voltage range is from 380V to 480V.
It is manufactured in the United Kingdom.
