Siemens Inverter Drive SINAMICS G115D Series, 2.2 kW Power Rating, 3 Phase, Panel Mount, 480V, 11.8 A 6SL3520-3XE42-2AF0

Siemens 6SL3520-3XE42-2AF0 Inverter Drive is a frequency converter from the SINAMICS G115D series that provides 2.2 kW power rating with 3 phase operation at a maximum supply voltage of 480V and maximum output current of 11.8 A. It is designed for panel mounting and offers IP66 and IP65 protection ratings, ensuring robust protection against environmental factors.

This inverter drive is engineered to support horizontal conveyor system applications with a wide operating temperature range from -30°C to 55°C, allowing use in diverse industrial environments. It supports output frequencies up to 550 Hz, enabling sophisticated motor speed control including encoderless vector control for asynchronous and synchronous reluctance motors with high efficiency (IE3 and IE4 classes).

The system offers integrated safety with Safe Torque Off (STO) functionality that uses fail-safe digital input or PROFIsafe protocols, enhancing operational safety for industrial automation processes.

This versatile drive supports SIMOGEAR 2KJ8 geared motors and operates without the need for control cabinets due to its installation on the machine, resulting in lower space requirements and reduced cooling needs. The design promotes quick installation, cabling, and commissioning, making it suitable for manufacturing, automation, material handling, and conveyor systems.

Part of the SINAMICS G115D series designed for modular, ready-to-connect drive solutions. Panel mount with IP66 and IP65 ingress protection for harsh environments. Operational from -30°C up to 55°C with maximum output frequency of 550 Hz.

Compatible with IE3 asynchronous or IE4 synchronous reluctance motors for energy-efficient operation. Integrated safety functions such as STO with fail-safe input enhance process security. Reduces engineer workload by eliminating the need for control cabinets and decreasing cooling requirements.

Certified to multiple industry standards including SEMI F47, REACH, and CE.

This Siemens Inverter Drive is ideal for use in industrial automation, manufacturing processes, HVAC systems, material handling conveyors, and other commercial applications requiring reliable 3 phase power conversion. It exemplifies Siemens' commitment to efficient, safe, and compact drive technology solutions.
