WAGO 714 Series Pluggable Terminal Block 8-Contact 3.5mm Pitch 1 Row 320V 10A Polyamide Housing 714-138

WAGO 714-138 is a high-quality pluggable terminal block designed for industrial and electronic applications requiring a reliable, compact connector. This product features an 8-contact configuration with a 3.5 mm pitch arranged in a single row, making it ideal for PCB implementations where space optimization is critical.

The terminal block housing is made of robust polyamide material, providing excellent insulation and mechanical strength. It is specifically moulded for Through Hole Reflow (THR) soldering compatibility, ensuring a lead-free and environmentally compliant assembly process. Tin-plated contacts enhance conductivity and protect against oxidation.

This male connector design incorporates separated pin slots that prevent pin damage during handling and provide touch-proof safety when unplugged. With a voltage rating of 320 V and a current carrying capacity of 10 A, it meets demanding electrical and safety standards. The compact dimensions (length 3.4 mm, width 29.4 mm, depth 6.9 mm) facilitate tight circuit board layouts.

The product complies with CSA, UL, and RoHS certifications, ensuring high-quality standards and environmental compliance. Its black polyamide housing color assists in easy identification and integration into electrical assemblies.

WAGO 714-138 terminal blocks are widely used in electronic devices, industrial control systems, automation equipment, and power connectors. Their modular design allows for flexible system configurations and maintenance ease.

Constructed with durable polyamide housing for insulation and mechanical strength. Designed for a maximum current of 10 A at 320 V voltage rating. Features tin-plated contacts for reliable electrical connection and corrosion resistance.

Compatible with THR soldering processes ensuring lead-free reflow soldering compliance. Includes separated pin slots to prevent damage and ensure touch-proof safety when unplugged. Black colored housing providing clear visibility and distinction in assemblies.

Compact dimensions with length 3.4 mm, width 29.4 mm, and depth 6.9 mm optimize PCB space utilization. Complies with international standards including CSA, UL, and RoHS for quality and environmental safety. Male connector gender suitable for various industrial and electronic component applications.
