Siemens Inverter Drive 5.5 kW 3 Phase SINAMICS G115D Series Wall Mount 380-480V 26.4A 6SL3520-2XK05-5AB0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-2XK05-5AB0 |
| IP Rating | IP66, IP65 |
| Mount Type | Wall |
| Overall Length | 240mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 5.5kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 26.4A |
| Standards/Approvals | EAC, KCC, REACH, SEMI F47, UL, CE, C-Tick (RCM), cUL |
| Maximum Supply Voltage | 480V |
| Overall Depth | 169mm |
| Minimum Supply Voltage | 380V |
| Compatible Motor Type | AC Motor |
Key Features
- Compact wall-mounted drive designed for AC motors with sensorless vector control.
- Supports output current up to 26.4 A and output frequency up to 550 Hz.
- Wide voltage supply range from 380 V to 480 V for flexible applications.
- Operates reliably in ambient temperatures from -30°C to 55°C with IP65/IP66 and UL type 4X protection.
- Includes air-cooled system with integrated fan and local remote control option.
- Complies with international standards including CE, UL, REACH, and SEMI F47.
- Constructed with durable materials suitable for industrial, automation, and control gear environments.
Product Description
Siemens 6SL3520-2XK05-5AB0 inverter drive is a robust and efficient SINAMICS G115D series wall-mounted drive system offering 5.5 kW power output for three-phase AC motors. It is specifically designed for industrial automation, electrical, and control systems requiring reliable motor speed and torque control. This drive supports sensorless vector control and encoderless torque control to enhance performance and operational precision.
The drive is engineered to function in harsh industrial environments with an operating temperature range from -30°C to 55°C and a high ingress protection rating of IP65/IP66, including UL type 4X compliance, ensuring protection against dust and water. It is powered from a wide supply voltage range of 380 to 480 V and can deliver a maximum output current of 26.4 A with a frequency output capability of up to 550 Hz.
The unit features wall mounting design with dimensions of 240 mm length, 425 mm width, and 169 mm depth. It is air-cooled via an integrated fan for efficient thermal management, and includes a 180 V DC brake voltage. This inverter drive is suitable for applications across industrial manufacturing, HVAC systems, water treatment, and other commercial automation sectors.
Standards such as EAC, KCC, REACH, SEMI F47, UL, CE, and C-Tick (RCM) are met, assuring global compliance and reliability. Manufactured in the United Kingdom, it delivers high performance in versatile AC motor control with added remote control functionalities for local and networked setup options.
Compact wall-mounted drive designed for AC motors with sensorless vector control. Supports output current up to 26.4 A and output frequency up to 550 Hz. Wide voltage supply range from 380 V to 480 V for flexible applications.
Operates reliably in ambient temperatures from -30°C to 55°C with IP65/IP66 and UL type 4X protection. Includes air-cooled system with integrated fan and local remote control option. Complies with international standards including CE, UL, REACH, and SEMI F47.
Constructed with durable materials suitable for industrial, automation, and control gear environments. Explore our extensive range of Inverter Drives at EnvMart for a variety of industrial automation and motor control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inverter drive has a power rating of 5.5 kW.
It can deliver a maximum output current of 26.4 A.
The operating temperature range is from -30°C to 55°C.
This model supports an output frequency of up to 550 Hz.
The dimensions are 240 mm in length, 425 mm in width, and 169 mm in depth.
It is compatible with AC motors.
The inverter drive has an IP rating of IP65/IP66, providing protection against dust and water.
This unit is designed for wall mounting.
It complies with several international standards including CE, UL, REACH, and SEMI F47.
It includes an air-cooled system with an integrated fan for efficient thermal management.
It is manufactured in the United Kingdom.
The minimum supply voltage is 380 V, while the maximum is 480 V.
