Siemens Inverter Drive 3 kW 3 Phase SINAMICS G115D Series 480V 15.4A 6SL3520-2XA03-0AB0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-2XA03-0AB0 |
| IP Rating | IP66, IP65 |
| Mount Type | Wall |
| Overall Length | 180mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 3kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 15.4A |
| Standards/Approvals | CE, C-Tick (RCM), UL, cUL, EAC, KCC, SEMI F47, REACH |
| Maximum Supply Voltage | 480V |
| Overall Depth | 134mm |
| Minimum Supply Voltage | 380V |
| Compatible Motor Type | AC Motor |
Key Features
- The SINAMICS G115D series offers a highly modular and preconfigured solution for conveyor system applications.
- Compatible with SIMOGEAR 2KJ8 geared motors and three phase asynchronous AC motors.
- Supports high efficiency synchronous reluctance motors with efficiency class IE4.
- Wall-mount type unit with IP66 and IP65 protection ratings for robustness in industrial environments.
- Operates within a temperature range of -30°C to 55°C ensuring reliable performance.
- Equipped with integrated safety functions including STO and fail-safe digital input F-DI or PROFIsafe.
- No control cabinet required, enabling space-saving installation on machines.
- Designed for quick installation, cabling, and commissioning with a versatile and robust build.
Product Description
Siemens 6SL3520-2XA03-0AB0 inverter drive is a 3 kW, 3 phase unit from the SINAMICS G115D series designed for industrial automation and conveyor system control. This inverter drive supports a supply voltage range from 380V minimum to 480V maximum, delivering a maximum output current of 15.4A and an output frequency up to 550Hz.
The device is designed for wall mounting and meets high ingress protection ratings of IP66 and IP65, making it suitable for harsh industrial environments. It supports AC motors including three phase asynchronous motors with efficiency class IE3 and synchronous reluctance motors with efficiency class IE4 for high energy efficiency.
The operating temperature range from -30°C to 55°C ensures reliable operation across various industrial settings. The compact dimensions of 425mm width, 180mm length, and 134mm depth facilitate easy integration.
Integrated safety features include the Safe Torque Off (STO) function with optional fail-safe digital input or PROFIsafe interface, adding critical safety for industrial automation processes. The modular design requires no control cabinet, reducing installation complexity, space requirements, and cooling demands.
This inverter drive is ideal for horizontal conveyor system applications demanding precise speed control and advanced encoderless vector control. It is compatible with Siemens SIMOGEAR 2KJ8 geared motors and built for robust, reliable, and user-friendly industrial use.
The SINAMICS G115D series provides a fully preconfigured and modular drive solution. Supports high efficiency asynchronous and synchronous reluctance motors. Offers integrated safety and easy installation without a control cabinet.
Achieves high IP protection suitable for tough industrial conditions. Enables precise speed control and advanced vector control applications. Compact and versatile design for space-saving machine installation. Designed for industrial automation, manufacturing, and material handling sectors.
Country of Origin: United Kingdom. Trust Siemens for reliable and efficient Inverter Drives. Explore EnvMart's wide range of Siemens industrial drives and automation components to enhance your industrial systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this inverter drive is 3 kW.
The maximum output current is 15.4A.
It operates within a temperature range of -30°C to 55°C.
This unit has IP66 and IP65 protection ratings, making it suitable for harsh industrial environments.
It is compatible with three phase asynchronous AC motors and high efficiency synchronous reluctance motors with efficiency class IE4.
The maximum supply voltage is 480V, while the minimum is 380V.
The output frequency can reach up to 550Hz.
The dimensions are 425mm in width, 180mm in length, and 134mm in depth.
It is designed for wall mounting, which facilitates space-saving installation.
It includes integrated safety functions such as Safe Torque Off (STO) and an optional fail-safe digital input or PROFIsafe interface.
It meets several standards including CE, C-Tick (RCM), UL, cUL, EAC, KCC, SEMI F47, and REACH.
This series is designed for industrial automation and conveyor system control applications, providing precise speed control.
