Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header, 8 Contacts, 2.54 mm 77311-118-08LF

Amphenol Communications Solutions 77311-118-08LF is a Bergstik Series vertical through hole pin header designed for robust electronic interconnection solutions. Featuring 8 male contacts arranged in a single row with a 2.54 mm pitch, this header enables precise and reliable board-to-board connections.

The phosphor bronze contact material combined with phosphor bronze plating ensures excellent conductivity and corrosion resistance. The thermoplastic housing material is high temperature rated, compatible with reflow solder processes, and facilitates durable mechanical support.

Operating within a temperature range of -65°C to 130°C, this pin header is UL approved (E66906), rated for 3A current and 1500V voltage, ensuring safety and performance in demanding industrial and electronic environments.

Its unshrouded design allows mating from either top or bottom, making it versatile for mezzanine stacking applications with varied stack heights, providing design flexibility.

The tail pin length of 3.05 mm and mating pin length of 5.84 mm assure secure mating contacts for long-term reliability in communications, industrial controls, and consumer electronic device assemblies.

Designed for board-to-board interconnection with through hole mount type. Constructed with phosphor bronze contacts and plating for durability. Utilizes high-temperature thermoplastic housing material suitable for reflow soldering.

Operates reliably between -65°C and 130°C temperatures. Rated for 3A current and 1500V voltage with UL approval E66906. Supports mezzanine stacking applications with variable stacking heights. Unshrouded header allowing mating from the top or bottom for flexible installation.

Tail pin length of 3.05 mm and mating pin length of 5.84 mm for secure connection.

This pin header is ideal for use in industrial controls, telecommunications, computing hardware, and other electronic equipment where dependable electrical connections are required. Made in France, its high quality construction meets rigorous industry standards.
