Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header, 5 Contacts, 2.54 mm 77311-118-05LF

Amphenol Communications Solutions 77311-118-05LF is a Bergstik Series Vertical Through Hole Pin Header designed for electronic interconnect applications requiring robustness and precision. It features a 2.54 mm pitch spacing with a single row of 5 contacts, enabling efficient board-to-board connections in a compact form factor.

The header housing is fabricated from high temperature thermoplastic, delivering excellent resistance to heat and mechanical stress, suitable for reflow soldering processes. Contacts are manufactured from phosphor bronze and plated similarly to enhance conductivity and corrosion resistance.

This pin header supports a continuous current rating of 3 amperes with a maximum voltage tolerance of 1500 volts, making it suitable for a wide range of industrial, commercial, and laboratory electrical equipment. Its operating temperature range from -65°C to 130°C allows reliable performance in varying ambient conditions.

The component is unshrouded with male pins and offers solder termination via through hole mounting. Its 3.05 mm tail pin length and 5.84 mm mating pin length provide secure connectivity and mechanical stability. It is compliant with UL standard E66906, assuring quality and conformance.

The design facilitates dual entry for mating from the top or bottom, offering significant flexibility in mezzanine and stacked board applications, adaptable to varying stack height requirements. This versatility makes it applicable in electronic assemblies across telecommunications, computing, instrumentation, and consumer electronics industries.

This pin header features a vertical orientation with one row of 5 contacts. Constructed with high temperature thermoplastic housing material for durability. Phosphor bronze contact material and plating ensure reliable electrical performance.

Supports a maximum operating voltage of 1500V and current of 3A. Suitable for applications requiring through hole mounting and solder termination. Features male contact gender and is unshrouded to allow dual entry mating from top or bottom.

Operates within a temperature range of -65°C to 130°C for diverse environments. Meets UL approval standard E66906, ensuring safety and reliability. Provides flexibility in stacking heights, ideal for mezzanine assemblies.

This Amphenol Communications Solutions PCB header is a high-quality component suited for electronics manufacturing, repair, and prototyping tasks. Explore more PCB Headers and connectors for your project needs at EnvMart.
