Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header 4 Contacts 2.54 mm Pitch 1 77311-101-04LF

Amphenol Communications Solutions 77311-101-04LF Bergstik Series vertical through hole pin header is engineered for board-to-board interconnects in various electronic equipment and devices. Featuring a 2.54 mm pitch and 1 row with 4 unshrouded contacts, this pin header is constructed with high temperature thermoplastic housing compatible with reflow soldering processes.

The phosphor bronze male contacts are plated with phosphor bronze to ensure excellent conductivity and mechanical reliability. The header supports currents up to 3 amperes and withstands voltages up to 1500 volts, meeting demanding electrical specifications.

Operating reliably in temperatures from -65 degrees Celsius up to 130 degrees Celsius, this component is rated for industrial and commercial use. The vertical orientation and variable spacing height enable mezzanine stacking, providing design flexibility for tight electronic assemblies.

With pill tail pin length of 2.41 mm for solder termination and mating pin length of 5.84 mm, the connector system ensures solid mechanical and electrical contact. The product holds UL approval E66906, confirming safety and compliance.

The Bergstik Series pin header is widely used across communication, computing, industrial control, and other electronic applications requiring high reliability. The product is manufactured in France with strict quality standards.

Unshrouded header design for flexible assembly. Phosphor bronze contacts with plating for excellent conductivity. High temperature thermoplastic housing suitable for reflow soldering. Supports up to 3A current and 1500V voltage for demanding applications.

Operating temperature range from -65°C to 130°C ensures durability. Vertical orientation allows compact mezzanine stacking. Pin lengths optimized for soldering and mating stability. UL approved under standard E66906 for quality assurance.

Designed for a wide range of electronic device interconnect solutions.

This connector is ideal for industrial, communication, and electronic assembly use where reliable, high-density board-to-board connections are essential. Explore more from Amphenol Communications Solutions and find additional PCB header options to meet your design needs at EnvMart.
