Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header 7 Contact(s) 2.54 mm Pitch 77311-101-07LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 77311-101-07LF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 130°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | UL Approval:E66906 |
| Contact Plating | Phosphor Bronze |
| Number of Contacts | 7 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.41mm |
| Mating Pin Length | 5.84mm |
| Standards/ApprovalsUL Approval | E66906 |
| UL Approval | E66906 |
Key Features
- Unshrouded design provides flexible mating options.
- Constructed with high temperature thermoplastic housing for durability.
- Contacts made of phosphor bronze and plated with phosphor bronze ensure excellent conductivity.
- Supports a current rating of 3A and voltage rating of 1500V for demanding applications.
- Compatible with through hole mounting methods for robust installation.
- Operating temperature range from -65°C to 130°C ensures performance in harsh environments.
- Single row with 7 contacts and 2.54 mm row pitch for standard spacing requirements.
- Suitable for mezzanine applications, allowing board stacking with variable height options.
Product Description
Amphenol Communications Solutions 77311-101-07LF Bergstik Series vertical through hole pin header features 7 male contacts arranged in a single row with 2.54 mm pitch. This unshrouded connector is designed for board-to-board interconnect solutions, providing reliable connections in electronic equipment and devices.
Manufactured using high temperature thermoplastic housing, this pin header withstands reflow soldering processes and operates across a wide temperature range from -65°C to 130°C. The phosphor bronze contacts and plating contribute to superior electrical performance and corrosion resistance.
The connector supports a current rating of 3A and voltage up to 1500V, making it suitable for a variety of industrial and electronic applications requiring robust power and signal transmission. Its through hole mount type ensures mechanical strength and durability on printed circuit boards.
This component is ideal for mezzanine applications, enabling flexible board stacking with variable spacing height. Its unshrouded design allows dual entry, mating from top or bottom, enhancing design versatility.
Typical use cases include industrial electronics, telecommunications, computing hardware, and other commercial applications demanding high-quality, reliable PCB connectivity solutions.
Unshrouded design provides flexible mating options. High temperature thermoplastic housing supports durability and reflow compatibility. Phosphor bronze contact material and plating ensure conductivity and corrosion resistance.
Current rating of 3A and 1500V voltage rating for demanding circuit requirements. Through hole mount type for secure PCB installation. Operating temperature range from -65°C to 130°C supports usage in harsh conditions. Single row, 7 contacts, 2.54 mm pitch suitable for standard PCB layouts.
Ideal for mezzanine and board stacking applications. Explore more PCB header components from Amphenol Communications Solutions on EnvMart for your electronic design needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3A and a voltage rating of 1500V, making it suitable for demanding applications.
It features a pitch of 2.54 mm and has 7 male contacts arranged in a single row.
The housing is made from high temperature thermoplastic, while the contacts are made of phosphor bronze and also plated with phosphor bronze for excellent conductivity.
The pin header operates within a temperature range of -65°C to 130°C, allowing it to perform in harsh environments.
It is designed for through hole mounting, ensuring robust installation on printed circuit boards.
This model utilizes a board-to-board connector system, allowing for reliable interconnections between PCBs.
Yes, it has UL approval under the designation E66906, indicating compliance with safety standards.
The termination type for this pin header is solder, which is common for PCB connections.
The tail pin length is 2.41 mm, which is designed for secure soldering onto a PCB.
The mating pin length is 5.84 mm, allowing for effective connections with compatible sockets.
This connector is suitable for mezzanine applications, enabling board stacking with variable height options, and is commonly used in industrial electronics, telecommunications, and computing hardware.
The orientation of this model is vertical, allowing for specific installation configurations on PCBs.
