SMC Pneumatic Guided Cylinder 32mm Bore, CQM Series, 40 mm Stroke, Double Acting, Aluminium Alloy Body, Model CDQMB32-40
Specifications
| Country of Origin | India |
|---|---|
| Brand | SMC |
| Body Material | Aluminium Alloy |
| Maximum Operating Pressure | 1 Mpa |
| Height | 45mm |
| Length | 90mm |
| Model | CDQMB32-40 |
| Gross Weight | 343g |
| Width | 58.5mm |
| Mount Type | Through Hole |
| Series | CQM |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -10°C |
| Stroke Length | 40mm |
| Bore Diameter | 32mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Cushioning Type | Rubber |
| Guide Type | Slide Bearing |
Key Features
- The cylinder is double-acting, providing efficient bidirectional movement.
- Constructed with an aluminium alloy body for durability and lightweight performance.
- Features a single rod type with rubber cushioning for smooth operation.
- Operates reliably between temperatures of -10°C to 70°C.
- Maximum operating pressure is rated at 1 Mpa for industrial strength use.
- Mounted through holes and includes slide bearing guide type for lateral load resistance.
- Offers a maximum piston speed of 500 mm/s ensuring fast actuation.
- Compact dimensions with a height of 45 mm, width of 58.5 mm, and length of 90 mm.
Product Description
SMC CDQMB32-40 Pneumatic Guided Cylinder is engineered for industrial pneumatic applications requiring precise guided motion. It features a 32mm bore diameter and a 40mm stroke length with a robust aluminium alloy construction that ensures strength and durability while maintaining lightweight characteristics.
This double-acting cylinder uses a single rod type design and incorporates rubber cushioning to minimize impact and prolong service life. Thermal conditions between -10°C and 70°C are supported, making it versatile for varied environments.
Mounting is facilitated via through holes, and the slide bearing guide type offers significant lateral load resistance, protecting the cylinder against side loading stresses. It can withstand a maximum operating pressure of 1 Mpa while delivering piston speeds up to 500 mm/s.
With compact dimensions (height 45mm, width 58.5mm, length 90mm), the cylinder is ideal for integration into mechanical systems across industrial, manufacturing, HVAC, and fluid power tool assemblies.
The cylinder is double acting, providing smooth push and pull motions. Aluminium alloy body ensures strength and corrosion resistance. Rubber cushioning reduces operational noise and impact. Slide bearing guide type designed for enhanced lateral stability.
Through hole mount type allows versatile installation options. Designed for operating pressures up to 1 Mpa. Functions efficiently within temperature ranges from -10°C to 70°C. Maximum piston speed of 500 mm/s supports high-speed cycling.
Compact size and light weight aid in seamless integration.
This Pneumatic Guided Cylinder is widely employed in industrial automation, fluid power systems, manufacturing lines, and pneumatic actuator applications where high lateral load tolerance and reliable performance are critical.
Explore the extensive SMC range of pneumatic cylinders and actuators at EnvMart for precision-engineered solutions tailored to your industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The bore diameter of this model is 32mm.
This cylinder has a stroke length of 40mm.
The maximum operating pressure is rated at 1 Mpa.
It operates efficiently within a temperature range of -10°C to 70°C.
The cylinder incorporates rubber cushioning to minimize impact and noise during operation.
It features a through hole mount type for versatile installation options.
The maximum piston speed is 500 mm/s, allowing for fast actuation.
The body is constructed from aluminium alloy, providing strength and lightweight characteristics.
The cylinder has a height of 45mm and a width of 58.5mm.
It is a double-acting cylinder, allowing for efficient bidirectional movement.
This cylinder uses a slide bearing guide type, which enhances lateral load resistance.
It is widely employed in industrial automation, fluid power systems, and manufacturing lines.
