Amphenol Communications Solutions EconoStik Series Vertical Through Hole Pin Header, 2 Contacts, 2.54 mm 10129378-902001BLF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 110V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 10129378-902001BLF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | EconoStik |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CHINA RoHS, EU RoHS, REACH/SvHC |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 5.84mm |
Key Features
- The header features a vertical, unshrouded orientation suitable for through-hole mounting.
- Contacts are made of copper alloy with 1μin gold plating for enhanced conductivity and durability.
- High-temperature thermoplastic housing ensures stable performance from -55°C to 105°C.
- Termination type is solder with a male contact gender and tail pin length of 3.05 mm.
- Mating pin length is 5.84 mm with the series classified as EconoStik.
- Connector system supports board-to-board applications, ideal for industrial control and electronic devices.
- Compliant with CHINA RoHS, EU RoHS, and REACH/SvHC standards for environmental safety.
Product Description
Amphenol Communications Solutions 10129378-902001BLF EconoStik Series Vertical Through Hole Pin Header is engineered for robust and precise electronic board interfacing. With 2 contacts arranged in a single row and a pitch of 2.54 mm, it is designed for efficient electrical connections in various industrial and commercial electronics.
The header utilizes a thermoplastic housing resistant to high temperatures, contributing to stable operation within a temperature range of -55°C to 105°C. Contacts are crafted from copper alloy and plated with 1μin gold, ensuring excellent electrical conductivity and resistance to corrosion over extended use. The solder termination type facilitates secure mounting on printed circuit boards (PCBs).
This connector is unshrouded and oriented vertically for through-hole mounting, making it suitable for diverse board-to-board connection applications. It supports current ratings up to 3A at 110V, aligning with multiple industrial requirements such as metering, test equipment, point-of-sale (POS) terminals, and communication devices.
The tail pin length of 3.05 mm and mating pin length of 5.84 mm allow for customized mating cycles and durability, tested to withstand up to 50 mating operations. This product complies with key environmental standards including China RoHS, EU RoHS, and REACH/SvHC, ensuring safety in manufacturing and end usage.
The vertical pin header is ideal for connecting electronic circuit boards in industrial control systems. Its gold-plated copper alloy contacts provide reliable, low-resistance connections. Durable thermoplastic housing supports high temperature and mechanical stresses.
Suitable for use in electronic measuring instruments, industrial automation, POS systems, and surveillance devices. Designed for through-hole mounting for enhanced mechanical retention and solder joint reliability. Environmentally compliant with RoHS and REACH directives.
Explore our extensive range of PCB connectors and electronic components at EnvMart to complement your industrial and electronic application needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 3A at 110V.
The contacts are arranged with a pitch of 2.54 mm.
It operates within a temperature range of -55°C to 105°C.
The contacts are made of copper alloy with gold plating, and the housing is constructed from high-temperature thermoplastic.
This model features 2 contacts arranged in a single row.
It uses a solder termination type for secure mounting on printed circuit boards (PCBs).
Yes, it complies with CHINA RoHS, EU RoHS, and REACH/SvHC standards.
The tail pin length is 3.05 mm.
The mating pin length is 5.84 mm.
This model has a vertical orientation suitable for through-hole mounting.
It is suitable for board-to-board applications in industrial control systems, electronic measuring instruments, and POS systems.
It is tested to withstand up to 50 mating operations.
