TDK-Lambda CC-E Series DC/DC Converter 12V DC Output 500mA Output Current 6W Through Hole DIP Package CC6-4812SF-E
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda CC-E DC/DC Converter, 12V dc/ 500 mA, 7 |
| Brand | TDK-Lambda |
| Efficiency | 0.86% |
| Length | 22.86mm |
| Model | CC6-4812SF-E |
| Depth | 21.1mm |
| Gross Weight | 5.8g |
| Width | 22.8mm |
| Mount Type | Through Hole |
| Series | CC-E |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 76V |
| Minimum Input Voltage | 36V |
| Number of Pins | 7 |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 500mA |
| Isolation Voltage | 500V |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Operates with input voltage range from 36V to 76V ensuring wide compatibility.
- High isolation voltage of 500V enhances operational safety.
- Compact DIP package with 7 pins facilitates easy installation.
- Maintains efficiency at 86 percent for reliable power conversion.
- Withstands wide operating temperature range from -40°C to 85°C for harsh environments.
- Suitable for telecommunication, industrial and consumer electronics applications.
- Single output configuration with output voltage adjustable by ±3 percent.
- Japanese origin guarantees quality and consistency in performance.
Product Description
TDK-Lambda CC6-4812SF-E DC/DC Converter is a compact and reliable power supply component delivering 12V DC output voltage at a maximum current of 500mA and a power rating of 6W. Designed with a through-hole DIP package, this converter suits various electronic assemblies requiring robust and isolated power conversion solutions.
This DC/DC converter supports an input voltage range of 36V minimum to 76V maximum, accommodating a 2:1 input ratio to adapt to varying source voltages. The device provides single output with an adjustable voltage range of ±3 percent to meet precise output requirements.
Featuring an isolation voltage of 500V, this module offers significant electrical isolation between input and output, enhancing safety and noise suppression in sensitive industrial and telecommunication equipment. Its DIP with 7 pins allows straightforward through-hole mounting on PCBs.
Efficiency is rated at approximately 86%, helping reduce energy loss during voltage conversion while supporting continuous operation in a wide temperature spectrum from -40°C to +85°C, ensuring durability under demanding environmental conditions.
The CC-E series converters serve well in applications ranging from industrial control systems and telecommunication devices to consumer electronics that require stable and efficient DC voltages. Originating from Japan, this component meets high manufacturing standards and reliability criteria.
Operates from 36V to 76V input voltage accommodating different DC power sources. Single output with 12V DC voltage and max current 500mA. Compact DIP package with 7 pins for through-hole PCB mounting. High isolation voltage of 500V ensures safety between input and output circuits.
Efficiency rating of 86% to minimize power losses during operation. Designed to function in temperatures from -40°C to 85°C for harsh environments. Adjustment of output voltage within ±3% provides precise control. Widely used in telecommunication, industrial equipment, and consumer electronic devices.
This product belongs to the DC/DC Converter category in Electronics & Electricals, suitable for applications demanding isolation, compactness, and reliable DC power conversion. Explore our range to find compatible components and complementary modules for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 36V to 76V, accommodating a 2:1 input ratio.
This unit has a maximum output power of 6W.
It provides a single output voltage of 12V DC.
The maximum output current for this model is 500mA.
The efficiency of this model is rated at approximately 86%.
This converter features a high isolation voltage of 500V, enhancing safety between input and output circuits.
The dimensions of this DC/DC converter are 22.86mm in length, 22.8mm in width, and 21.1mm in depth.
It is designed to operate within a temperature range of -40°C to +85°C.
The DIP package of this model has 7 pins for through-hole mounting.
Yes, the output voltage can be adjusted by ±3% to meet precise requirements.
This model is suitable for telecommunication, industrial equipment, and consumer electronics applications.
This product originates from Japan, ensuring quality and consistency in performance.
