TDK-Lambda CC-E Series DC/DC Converter, 12V DC Output, 250mA, 36V-76V Input, 3W Power, Surface Mount CC3-4812SR-E

The TDK-Lambda CC-E series DC/DC Converter model CC3-4812SR-E provides a precise 12V DC output at 250mA from a compact surface mount package. It operates with input voltages from 36V up to 76V, making it versatile for various electronic and industrial power supply requirements.

This converter offers a maximum output power of 3W and features an isolation voltage of 500V, ensuring enhanced electrical safety through input-output isolation. The efficiency is rated at approximately 81%, optimizing energy consumption and reducing thermal load during operation.

Designed for demanding applications, it operates effectively across a wide temperature range from -40°C to 85°C, suitable for harsh industrial and telecommunications environments. The lightweight and compact dimensions (Length: 26.16mm, Width: 22.8mm, Depth: 16.6mm) facilitate integration into space-constrained systems.

The package includes a 7-pin surface mount device with a 2:1 input ratio, allowing flexibility in input voltage configurations. The CC-E series is known for its ultra-compact footprint with through-hole or surface mount options and supports single output voltage configurations.

Ideal for use in telecommunications, industrial control systems, consumer electronics, and other applications requiring isolated DC voltage conversion, the CC3-4812SR-E ensures dependable performance, long life, and compliance with environmental standards like RoHS.

Compact surface mount design ideal for space-constrained applications. Wide input voltage range from 36V to 76V ensuring versatile use. Output current of 250mA with stable 12V DC output voltage. High isolation voltage of 500V to ensure electrical safety.

Operating temperature range from -40°C to 85°C for harsh environments. High efficiency of approximately 81% minimizes energy loss. Robust series CC-E construction with 7 pins and surface mount package type. Extremely low weight of 4.5g making it suitable for lightweight electronic devices.

RoHS compliant ensuring environmental and safety standards. Suitable for telecommunications, industrial equipment, and consumer electronics. Manufactured in Japan ensuring reliable quality standards. Explore more DC/DC Converters and related power supply components on EnvMart for robust industrial and electronic design solutions.
