TDK-Lambda CC-E DC/DC Converter 3.3V DC 2.5A 18V Input Through Hole DIP Package CC10-1203SF-E
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK-Lambda |
| Efficiency | 0.84% |
| Length | 8.5mm |
| Model | CC10-1203SF-E |
| Depth | 22.6mm |
| Gross Weight | 10g |
| Width | 35.56mm |
| Mount Type | Through Hole |
| Series | CC-E |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 18V |
| Output Voltage | 3.3 V |
| Minimum Input Voltage | 9V dc |
| Number of Pins | 7 |
| Output Voltage 1 | 3.3V dc |
| Output Current 1 | 2.5A |
| Isolation Voltage | 500V |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Compact design suitable for PCB mounting through hole type.
- Output current rated at 2.5 amperes ensuring steady power supply.
- Input voltage range from 9V dc minimum to 18V maximum supports versatile power sources.
- High isolation voltage of 500V enhances operational safety.
- Operating temperature range from -40°C to +85°C supports harsh environments.
- Efficient conversion with 0.84% efficiency rating.
- Single output configuration with 7 pins for straightforward integration.
- Made in Japan assuring high quality and manufacturing standards.
Product Description
TDK-Lambda CC10-1203SF-E is a high-performance DC/DC converter providing a stable 3.3V DC output at up to 2.5A current, designed for use in industrial and electronic equipment requiring reliable power conversion. This model operates from a DC input range between 9V to 18V, featuring a through-hole DIP package with 7 pins optimized for printed circuit board mounting. Its compact dimensions (8.5mm length, 35.56mm width, 22.6mm depth) and low weight of 10 grams support efficient space utilization in electronic designs.
The device offers an isolation voltage of 500V, ensuring electrical safety by providing galvanic isolation between input and output. Designed to function in a broad temperature range from -40°C to +85°C, this converter is suitable for demanding environments such as telecommunications, industrial equipment, and consumer electronics. With an input ratio of 2:1 and output voltage adjustment capability within ±3%, it allows flexibility in varying applications.
Featuring an efficiency of 0.84%, the CC10-1203SF-E optimizes power usage to minimize heat generation and energy loss. The product is RoHS compliant and manufactured in Japan, reflecting high quality and reliability standards associated with TDK-Lambda products.
This single output converter is part of TDK-Lambda’s CC-E series, known for ultra-compact designs available in both through-hole and surface mount technology versions. It is ideal for applications requiring isolation and voltage conversion in compact electronic assemblies.
Compact through-hole DIP package ideal for PCB mounting. 3.3V output voltage providing stable power supply at 2.5A current. Wide input voltage range from 9V dc to 18V supports versatile power sources. High isolation voltage (500V) enhances operational safety.
Supports operating temperatures from -40°C up to 85°C. Efficient power conversion with 0.84% efficiency. Small footprint with length 8.5mm, width 35.56mm, depth 22.6mm. Lightweight design with gross weight approx 10 grams.
Manufactured in Japan ensuring premium quality. Suitable for telecommunication, industrial, and consumer electronics. Explore EnvMart’s electronics components categories for more TDK-Lambda DC/DC Converters and power supply solutions tailored to industrial and technological applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The converter provides a stable output voltage of 3.3V DC with a maximum output current rating of 2.5A.
It operates within an input voltage range of 9V DC minimum to 18V maximum.
The efficiency rating of this model is 0.84%.
This model features a high isolation voltage of 500V, enhancing operational safety.
The dimensions of this converter are 8.5mm in length, 35.56mm in width, and 22.6mm in depth.
It is designed for through-hole mounting, suitable for PCB integration.
The operating temperature range is from -40°C to +85°C, making it suitable for harsh environments.
This model has a total of 7 pins for its single output configuration.
The maximum input voltage for this model is 18V.
This converter is suitable for use in telecommunications, industrial equipment, and consumer electronics.
It is manufactured in Japan, ensuring high quality and manufacturing standards.
The maximum output power of this converter is 10W.
