TDK-Lambda CC10-4805SF-E CC-E Series DC/DC Converter 5V DC Output 2A 36V-76V Input 10W Through Hole DIP Package Japan
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda CC-E DC/DC Converter, 5V dc/ 2 A, 76V I |
| Brand | TDK-Lambda |
| Efficiency | 0.86% |
| Length | 8.5mm |
| Model | CC10-4805SF-E |
| Depth | 22.6mm |
| Gross Weight | 10g |
| Width | 35.56mm |
| Mount Type | Through Hole |
| Series | CC-E |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 76V |
| Minimum Input Voltage | 36V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 2A |
| Isolation Voltage | 500V |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- This converter supports high efficiency of 86 percent.
- It is designed for isolation voltage up to 500V to ensure safety between input and output.
- The operating temperature range spans from -40°C to 85°C for versatile environments.
- The compact design includes dimensions of 8.5mm length, 35.56mm width, and 22.6mm depth.
- Featuring 7 pins, this DIP package converter is suitable for through hole mounting.
- The series CC-E is known for ultra-compact, isolated DC-DC conversion suitable for telecom and industrial applications.
- It delivers a stable output voltage with ±3% adjustment range.
- Country of origin is Japan ensuring quality manufacture.
Product Description
TDK-Lambda CC10-4805SF-E is a high-reliability DC/DC converter from the CC-E series, offering a 5V DC output at 2A with a robust 36V to 76V input voltage range and a maximum output power of 10W in a compact Through Hole DIP package.
These converters provide galvanic isolation of 500V between input and output, enhancing operational safety in sensitive electronic equipment such as telecommunications, industrial control, and consumer electronics.
The efficiency at 86 percent minimises heat dissipation, while the wide operating temperature range from -40°C to 85°C allows deployment in industrial and outdoor environments. The package dimensions are 8.5mm (L) x 35.56mm (W) x 22.6mm (D) with a 7-pin DIP footprint for through hole mounting, allowing easy integration on printed circuit boards.
This series offers stable performance with an output voltage adjustment range of ±3 percent, suitable for systems requiring precise voltage regulation.
The CC10-4805SF-E converter is RoHS compliant and represents a reliable choice for power conversion needs in demanding applications across telecommunications, industrial, laboratory, and consumer sectors.
This converter supports high efficiency of 86 percent. It is designed for isolation voltage up to 500V to ensure safety between input and output. The operating temperature range spans from -40°C to 85°C for versatile environments.
The compact design includes dimensions of 8.5mm length, 35.56mm width, and 22.6mm depth. Featuring 7 pins, this DIP package converter is suitable for through hole mounting. The series CC-E is known for ultra-compact, isolated DC-DC conversion suitable for telecom and industrial applications.
It delivers a stable output voltage with ±3% adjustment range. Country of origin is Japan ensuring quality manufacture. Explore more DC/DC Converters and other electronic power solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a stable output voltage of 5V DC with a maximum output current of 2A.
The input voltage range for the CC10-4805SF-E is from 36V to 76V.
The maximum output power of the CC10-4805SF-E is 10W.
This converter has an efficiency rating of 86 percent.
The isolation voltage for the CC10-4805SF-E is designed up to 500V, ensuring safety between input and output.
The dimensions of the CC10-4805SF-E are 8.5mm in length, 35.56mm in width, and 22.6mm in depth.
The operating temperature range for the CC10-4805SF-E spans from -40°C to 85°C.
This model features 7 pins for through hole mounting.
The CC10-4805SF-E is designed for through hole mounting, suitable for integration on printed circuit boards.
This converter is part of the CC-E series, known for ultra-compact, isolated DC-DC conversion.
The country of origin for the CC10-4805SF-E is Japan.
The CC10-4805SF-E is suitable for telecommunications, industrial control, and consumer electronics applications.
