Eaton ZBT Contactor Relay 690V AC Coil 32A 15kW 1 NO/1 NC 190942 ZBT32-32

Eaton 190942 ZBT32-32 Contactor Relay is a high-performance electrical component designed for industrial automation and control applications. Featuring a 690V AC coil, this relay manages contact currents up to 32 amperes and effectively handles power loads up to 15kW. The product is part of the ZBT series with a frame size of ZBT12 and supports direct mounting for straightforward installation.

This contactor relay includes a robust configuration with 1 Normally Open (NO) and 1 Normally Closed (NC) contact, facilitated through screw-type terminals ensuring secure electrical connections. It is equipped with 2 auxiliary contacts, also configured as 1 NO and 1 NC, adding control flexibility to electrical circuits.

Designed to operate within a wide temperature range from -25°C minimum to 55°C maximum, the relay is suited for various industrial environments and complies with international standards VDE and IEC/EN 60947. Its compact dimensions - 97mm in length, 27mm in width, and 85mm in depth - make it suitable for integration into electrical panels and control systems where space optimization is critical.

The relay features a trip-free release mechanism along with manual or automatic reset pushbuttons, enhancing operational safety and convenience. Eaton, formerly known as Moeller, ensures that this contactor relay meets high-quality standards and reliable performance requirements for industrial applications including automation, manufacturing control gear, electrical distribution, and HVAC systems.

Designed for direct mounting with a ZBT series frame size. Equipped with 1 Normally Open and 1 Normally Closed contact configuration. Operational temperature range from -25°C to 55°C for varied environments. Terminal type uses screw connections for reliable wiring.

Complies with VDE and IEC/EN 60947 standards for safety and performance. Compact dimensions: Length 97mm, Width 27mm, Depth 85mm to fit electrical panels efficiently. Includes 2 auxiliary contacts with 1 NO and 1 NC configuration for control circuit flexibility.

Control circuit voltage rated at 690V ensuring compatibility with industrial systems. Trip-free release feature and manual/auto reset for enhanced safety and usability. Manufactured in China following stringent quality protocols.

Eaton contactor relays are widely used in industrial automation, manufacturing, electrical distribution, HVAC controls, and other commercial electrical control systems. This model, 190942 ZBT32-32, is tailored for applications requiring a robust, reliable relay capable of handling moderate power and current loads with exceptional safety and durability.
