Amphenol Limited MIL Spec Circular Connector 2 Contacts Copper Alloy Gold Plated Straight 1.2kV 22A Bayonet 62GB-16F10-02SN
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 1.2kV |
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 22A |
| Model | 62GB-16F10-02SN |
| Temperature Operating Range | -55°C to 125°C |
| Mount Type | Cable |
| Contact Material | Copper Alloy |
| Series | 62 GB |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 10 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Wire gauges and current carrying capabilities | Upto 45A and size 24 to 8 AWG wires |
Key Features
- Designed with a straight orientation and bayonet mating type for secure connection.
- Shell size 10 with cable mount type suitable for rugged applications.
- Supports operating temperatures from -55°C to 125°C ensuring high reliability.
- Meets MIL-DTL-26482 military standard for durability and performance.
- Crimp termination type with strain relief for secure cable connections.
- Connector contacts are gold plated to ensure excellent conductivity and corrosion resistance.
- Constructed with a copper alloy contact material for robust electric and mechanical performance.
- Suitable for use in harsh environments and military applications.
Product Description
Amphenol Limited 62GB-16F10-02SN MIL Spec Circular Connector is engineered for high-performance industrial and military applications, providing robust and reliable connections in challenging environments. This circular connector features 2 gold-plated female contacts crafted from copper alloy, ensuring excellent conductivity and corrosion resistance. The connector operates at a voltage of 1.2kV with a current capacity up to 22A, making it suitable for moderate high-power applications.
The straight orientation and bayonet-type mating system offer secure and quick connections. Its shell size 10 and cable mount type offer versatility in installation. Designed to comply with the MIL-DTL-26482 military specification, this connector guarantees durability and resistance under rigorous conditions with an operating temperature range from -55°C to 125°C.
This connector utilizes a crimp termination style and includes strain relief to maintain cable integrity during use. The combination of a copper alloy contact base and gold plating ensures both mechanical strength and excellent electrical performance. Ideal for use in military, aerospace, industrial, and heavy-duty electronic equipment, it excels in harsh environmental conditions where reliability is critical.
Manufactured in the United Kingdom, the 62GB series connectors incorporate keyway orientation to reduce mismating risk. The aluminum shell with a resilient neoprene insulator and rear wire sealing grommet provides a liquid-tight assembly ensuring environmental protection.
Gold plated contacts ensure long-lasting conductivity and corrosion resistance. Compliance with MIL-DTL-26482 ensures rugged military-grade reliability. Wide operating temperature range from -55°C to 125°C accommodates extreme environments.
Crimp termination and strain relief enhance cable connection security. Copper alloy contacts provide reliable electric and mechanical performance. Bayonet mating type for quick and secure connector engagement. Shell size 10 offers compatibility with various cable diameters.
Keyway orientation minimizes mismating around multiple connectors. Manufactured under stringent quality standards in the United Kingdom.
Explore EnvMart for more Mil Spec Circular Connectors and trusted industrial-grade electronic components from Amphenol Limited and other leading brands. Optimize your application reliability with premium connectors designed for demanding specifications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a voltage rating of 1.2kV, making it suitable for moderate high-power applications.
This model supports a current capacity of up to 22A.
It operates within a temperature range of -55°C to 125°C, ensuring reliability in extreme environments.
The connector utilizes a crimp termination type, which enhances the security of cable connections.
The connector features 2 female contacts, which are gold plated for improved conductivity.
This connector has a shell size of 10, which accommodates various cable diameters.
It features a bayonet mating type, allowing for secure and quick connections.
The contacts are made from copper alloy and are gold plated to ensure excellent conductivity and corrosion resistance.
Yes, it meets the MIL-DTL-26482 military standard, ensuring durability and performance in rugged conditions.
The 62GB-16F10-02SN connector is manufactured in the United Kingdom.
It is suitable for military, aerospace, industrial, and heavy-duty electronic equipment applications.
The connector incorporates keyway orientation to reduce the risk of mismating around multiple connectors.
