Lumberg Minimodul Series Right Angle Through Hole PCB Header 4 Contact(s) 2.5 mm Pitch 1 Row Shrouded 2,5 MSFW 04

Lumberg 2,5 MSFW 04 Minimodul Series Right Angle Through Hole PCB Header is designed for reliable cable-to-board connections in electronic and industrial applications. This PCB header features 4 contacts arranged in a single row with a 2.5 mm pitch, making it suitable for compact designs and precise connectivity.

The housing material is robust glass filled polyamide, providing excellent electrical insulation and mechanical strength. The brass contact pins are plated with tin to ensure durable and corrosion-resistant electrical performance. Its through hole mounting style guarantees a secure fit to the printed circuit board, suitable for industrial, laboratory, and commercial electronics manufacturing.

This right angle header supports currents up to 5 amperes and operates reliably within temperatures ranging from -40°C to 120°C, accommodating a wide range of environmental conditions. The shrouded design enhances contact protection, preventing accidental shorts and physical damage during handling or operation.

The PCB header is terminated by solder, facilitating firm and reliable assembly in production environments. It meets critical international standards including DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11, ensuring safety and compliance with electrical installation requirements.

These connectors are ideal for use in industrial machinery, electronic equipment, power connectors, and wire housings requiring secure and durable wire-to-board connections. The compact design supports efficient harness assembly suitable for medium volume production runs.

Constructed with glass filled polyamide housing for durability. Supports current up to 5 A, ideal for low to medium load signals. Through hole mount type ensures secure PCB integration. Brass contacts plated with tin guarantee reliable electrical connection.

Operating temperature range from -40°C to 120°C for versatile environments. Right-angle orientation enables compact board layouts. Shrouded design provides enhanced contact protection and reliability. Termination type is solder, facilitating secure assembly.

Compliance with DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards. Explore additional PCB Headers, connectors, and electronic components in the Electronics & Electricals category at EnvMart to find the best fit for your project requirements.
