Vishay Single Layer Ceramic Capacitor 270 pF 2 kV dc ±10% S3N Dielectric Through Hole 125°C Max Op. Temp. F271K25S3NP63K7R
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 2kV dc |
| Diameter | 6.5mm |
| Brand | Vishay |
| Height | 40mm |
| Model | F271K25S3NP63K7R |
| Width | 18mm |
| Mount Type | Through Hole |
| Series | F |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 270pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Radial |
| Dissipation Factor | 0.2% |
| Standards/Approvals | EC, RoHS |
| Package/Case | Disc |
| Pin Count | 2 |
| Dielectric | S3N |
| Suppression Class | Class I |
Key Features
- The capacitor uses S3N dielectric providing stability up to 125°C maximum operating temperature.
- Through hole radial mounting with disc package and kinked leads ensures easy PCB assembly.
- Capacitance tolerance is ±10% with a dissipation factor of 0.2% for precise electronic applications.
- Designed for use in switching power supplies, high frequency ballast, snubber, and high voltage circuits.
- Operates reliably within a temperature range from -30°C to 125°C with 2 mm lead spacing options available.
- Conforms to IEC 60384-9 and RoHS environmental standards.
Product Description
Vishay F271K25S3NP63K7R is a Single Layer Ceramic Capacitor offering a capacitance of 270 pF and rated for 2 kV direct current operation with a tolerance of ±10%. It employs an S3N type ceramic dielectric known for high reliability and low losses in high frequency and high voltage applications.
This capacitor is constructed with a ceramic disc body, silver-plated on both sides, encapsulated in an epoxy-resin that is flame resistant according to UL 94 V-0 standards. The radial terminal leads are tinned copper wires designed for through-hole mounting with kinked leads for stable PCB placement.
With a maximum operating temperature of 125°C and a dissipation factor of 0.2%, this component is suitable for highly demanding environments such as switching mode power supplies (SMPS), high frequency ballast circuits, snubbers, and other high voltage electronic circuits requiring small size and stable capacitance.
The capacitor’s physical dimensions include a height of 40 mm, diameter 6.5 mm, and width 18 mm, offering compact form factor integration. It meets IEC 60384-9 standards and complies with RoHS directives for hazardous substances.
This radial lead capacitor is ideal for industrial, electronics manufacturing, and repair use cases requiring dielectrically stable ceramic capacitors with secure mounting options.
The capacitor uses S3N dielectric providing stability up to 125°C maximum operating temperature. Through hole radial mounting with disc package and kinked leads ensures easy PCB assembly. Capacitance tolerance is ±10% with a dissipation factor of 0.2% for precise electronic applications.
Designed for use in switching power supplies, high frequency ballast, snubber, and high voltage circuits. Operates reliably within a temperature range from -30°C to 125°C with 2 mm lead spacing options available. Conforms to IEC 60384-9 and RoHS environmental standards.
Explore more Vishay electronic components and capacitors at EnvMart for your industrial and laboratory power and signal conditioning needs.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 270 pF.
It is rated for a maximum voltage of 2 kV dc.
This unit operates reliably within a temperature range from -30°C to 125°C.
The capacitance tolerance is ±10%.
The dissipation factor is 0.2%.
It employs an S3N type ceramic dielectric.
The dimensions are 40 mm in height, 6.5 mm in diameter, and 18 mm in width.
This model features through-hole radial mounting with kinked leads for stable PCB placement.
It conforms to IEC 60384-9 and RoHS environmental standards.
It is designed for use in switching power supplies, high frequency ballast circuits, snubbers, and high voltage applications.
It has radial terminal leads made of tinned copper wires.
The capacitor is packaged in a disc configuration.
