Vishay Single Layer Ceramic Capacitor 150 pF 1kV DC ±10% S3N Dielectric F Series Through Hole Radial F151K25S3NN63J5R

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single Layer Ceramic Capacitor 150 pF 1kV DC ±10% S3N Dielectric F Series Through Hole Radial F151K25S3NN63J5R

Name: Vishay Single Layer Ceramic Capacitor 150 pF 1kV DC ±10% S3N Dielectric F Series Through Hole Radial F151K25S3NN63J5R
Brand: Vishay
SKU: 103064
Price: 0.13 USD
Availability: InStock



Category Single Layer Ceramic Capacitors Brand Vishay Condition New

Specifications

Country of Origin	India
Voltage	1kV dc
Diameter	6.5mm
Brand	Vishay
Height	40mm
Model	F151K25S3NN63J5R
Width	18mm
Mount Type	Through Hole
Series	F
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	150pF
Minimum Operating Temperature	-30°C
Terminal type	Radial
Dissipation Factor	0.2%
Standards/Approvals	EC, RoHS
Package/Case	Ceramic Disc
Pin Count	2
Dielectric	S3N
Suppression Class	Class I

Key Features

Class 1 S3N dielectric provides stable capacitance with low dissipation factor of 0.2%.
Manufactured with radial through-hole mounting and kinked leads for secure PCB mounting.
Temperature operating range from -30°C to 125°C suitable for demanding environments.
Ceramic disc package with silver-plated electrodes ensures high reliability and low losses.
Designed for applications in switched-mode power supplies, high frequency ballasts, and snubber circuits.
Epoxy resin encapsulation rated UL 94 V-0 flame resistant for enhanced safety.
Accurate capacitance tolerance of ±10% supports precise circuit design requirements.

Product Description

Vishay F151K25S3NN63J5R is a single layer ceramic capacitor featuring 150 pF capacitance and a high voltage rating of 1 kV DC. This capacitor belongs to the F series and uses a class 1 S3N dielectric material optimized for low losses and stability.

It is designed with through-hole radial terminal leads made from tinned copper with diameters of 0.6 mm or 0.8 mm and kinked for reliable PCB insertion. The capacitor encapsulation employs epoxy resin complying with UL 94 V-0 flame resistance standard, ensuring safety in demanding industrial and electronic applications.

This Vishay capacitor operates reliably in a wide temperature range from -30°C to a maximum of 125°C. The ceramic disc package measures 40 mm in height, 18 mm in width, and has a diameter of 6.5 mm, suitable for compact circuit board layouts.

Typical applications include switched-mode power supplies (SMPS), high-frequency ballast circuits, snubber and high voltage circuits where stable capacitance and low dissipation are critical. The capacitance tolerance is ±10%, providing designers with accurate and consistent performance.

High reliability with low losses enabled by the S3N dielectric class 1 ceramic. Radial through-hole mounting with kinked leads for mechanical stability. Epoxy-resin encapsulation flame resistant to UL 94 V-0 for industrial safety standards.

Wide operating temperature range from -30°C to 125°C ensuring versatility. Ideal for power supply circuits, ballasts, and snubber applications. Package dimensions optimized for moderate size electronic assemblies. Capacitance tolerance of ±10% facilitating precise electronic circuit design.

The set contains one Vishay ceramic capacitor, model F151K25S3NN63J5R. This component is suited for industrial, commercial, and electronic manufacturing sectors requiring dependable passive components.
