Preci-Dip 832 Series Straight Through Hole Pin Header, 12 Contacts, 2 mm Pitch, 2 Row, Unshrouded 832-80-012-10-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polymer |
| Contact Material | Brass |
| Series | 832 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- Constructed with a fibreglass reinforced polymer housing for durability.
- Brass male contacts with tin plating ensure reliable conductivity.
- Rated for 150V and 3A current capacity for standard electronic applications.
- Suitable for through-hole mounting with a straight pin orientation.
- Operates reliably between -55°C and 125°C for temperature resilience.
- Pin diameter of approximately 0.47 mm and tail length of 2.9 mm provide secure insertion and soldering.
- Complies with UL 94V-0 flammability standard ensuring safety in PCB assemblies.
- Manufactured in Switzerland with high quality standards.
Product Description
Preci-Dip 832-80-012-10-001101 is a high-quality 2 mm pitch Straight Through Hole Pin Header featuring 12 male contacts arranged in 2 rows. With a voltage rating of 150V and a current capacity of 3A, this unshrouded pin header is designed for dependable electrical connections in electronic circuit boards.
The housing is made from fibreglass reinforced polymer, providing robust mechanical strength and resistance to environmental stress. The brass contacts are tin-plated, enhancing conductivity and corrosion resistance. This component supports solder termination and through-hole mounting, enabling secure and reliable PCB assembly.
The pin diameter is approximately 0.47 mm with a tail length of 2.9 mm, optimized for standard PCB layouts. Operating temperature ranges from -55°C to 125°C, making it suitable for a wide range of industrial and electronic applications.
The device meets UL 94V-0 safety standards, ensuring flame retardance and safe use in electronics manufacture. Manufactured in Switzerland, it adheres to stringent quality control to deliver consistent performance.
This pin header is ideal for industrial electronics, manufacturing, laboratory equipment, and electronic component assembly where precision, safety, and reliability are paramount. Constructed with fibreglass reinforced polymer housing for durability.
Brass male contacts with tin plating ensure reliable conductivity. Rated for 150V and 3A current capacity for standard electronic applications. Suitable for through-hole mounting with a straight pin orientation. Operates reliably between -55°C and 125°C for temperature resilience.
Pin diameter of approximately 0.47 mm and tail length of 2.9 mm provide secure insertion and soldering. Complies with UL 94V-0 flammability standard ensuring safety in PCB assemblies. Manufactured in Switzerland with high quality standards.
Explore similar PCB header components and connectors on EnvMart to optimize your electronic projects and production line efficiency.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header is rated for a voltage of 150V and a current capacity of 3A, suitable for standard electronic applications.
It features a 2 mm pitch and has 12 contacts arranged in 2 rows.
The housing is made from fibreglass reinforced polymer, while the contacts are brass with tin plating for enhanced conductivity.
This model operates reliably within a temperature range of -55°C to 125°C.
It is designed for through-hole mounting with a straight pin orientation, allowing for secure PCB assembly.
The pin diameter is approximately 0.47 mm, and the tail length is 2.9 mm, optimized for secure insertion and soldering.
Yes, it complies with the UL 94V-0 flammability standard, ensuring safety in PCB assemblies.
This pin header uses solder termination, which is common for secure connections in PCB applications.
It is manufactured in Switzerland, adhering to high quality standards.
The contacts are male, which is typical for pin headers used in electronic connections.
Yes, it is suitable for various industrial electronics, manufacturing, and laboratory equipment applications.
This model is part of the Preci-Dip 832 series, known for its reliable electrical connections in PCB designs.
