STMicroelectronics Brushed DC Motor Driver IC, 20-Pin PDIP, 52 V, 1.4 A, Full Bridge Configuration L6225N
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 4.59mm |
| Length | 24.8mm |
| Model | L6225N |
| Width | 7.1mm |
| Motor Type | Brushed DC Motor |
| Mount Type | Through Hole |
| Series | L6225 |
| Configuration | Full Bridge |
| Output Current | 2.8A |
| Maximum Operating Temperature | 150°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 20 |
| Maximum Collector Emitter Voltage Vceo | 52V |
| Maximum Supply Voltage | 52V |
| Minimum Supply Voltage | 8V |
| Supply Current | 1.4A |
| Maximum IGBT Collector Current | 1.4A |
| Typical Switching Frequency | 100kHz |
Key Features
- Supports brushed DC motors with full bridge configuration.
- Maximum collector emitter voltage of 52 V ensures robust operation.
- Output current capability up to 2.8 A for efficient motor driving.
- Contains 20 pins in a through-hole PDIP package for easy PCB mounting.
- Operates over a voltage range of 8 V to 52 V for flexible power supplies.
- Typical switching frequency of 100 kHz to enable efficient motor control.
- Operating temperature ranges from -40°C to 150°C for demanding industrial environments.
- Compact dimensions with length 24.8 mm, width 7.1 mm, and height 4.59 mm.
Product Description
STMicroelectronics L6225N is a highly reliable Motor Driver IC engineered for controlling brushed DC motors. This full bridge driver IC supports a maximum collector emitter voltage of 52 V and a peak output current of 2.8 A, making it suitable for a wide range of industrial motor control applications. The device comes in a 20-pin Through Hole PDIP package, facilitating secure and easy mounting on printed circuit boards.
Designed to interface seamlessly with microcontrollers, DSPs, and FPGAs, the L6225N allows precise logic control of motor speed and direction through its full bridge configuration. Its typical switching frequency of 100 kHz ensures efficient performance and reduced electromagnetic interference.
The device is rated for operation in harsh environments with an extended temperature range from -40°C up to 150°C, suitable for automotive and industrial power driver needs. The supply current of 1.4 A and maximum IGBT collector current rating of 1.4 A provide robust handling of motor loads.
Physical dimensions are compact with a length of 24.8 mm, width of 7.1 mm, and height of 4.59 mm. It features a through-hole mount type facilitating integration into various motor control systems. The package type is PDIP, commonly used for prototyping and industrial applications.
The L6225N series power drivers from STMicroelectronics are engineered for driving motors and complex loads, ensuring reliable and efficient power delivery. This IC is ideal for enhancing production efficiency in systems requiring motor control, including industrial automation, robotics, and manufacturing equipment.
Supports brushed DC motors with full bridge configuration. Maximum collector emitter voltage of 52 V. Output current up to 2.8 A. 20-pin Through Hole PDIP package. Voltage range from 8 V to 52 V. 100 kHz switching frequency.
Operating temperature from -40°C to 150°C. Compact size: 24.8 mm × 7.1 mm × 4.59 mm. Supply current 1.4 A. Designed for microcontroller, DSP, FPGA controlled motor systems.
STMicroelectronics products are widely used in industrial, automotive, and automation environments. Explore further power management and motor control components on EnvMart to complement your designs and improve system performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum collector emitter voltage of this model is 52 V, ensuring robust operation for motor control applications.
It has an output current capability of up to 2.8 A, making it suitable for driving various brushed DC motors efficiently.
The typical switching frequency is 100 kHz, which helps in achieving efficient motor control and reducing electromagnetic interference.
The L6225N operates within a temperature range of -40°C to 150°C, suitable for demanding industrial environments.
This motor driver IC comes in a 20-pin Through Hole PDIP package, facilitating easy mounting on printed circuit boards.
The dimensions of this model are 24.8 mm in length, 7.1 mm in width, and 4.59 mm in height.
It supports brushed DC motors with a full bridge configuration, making it versatile for various motor control applications.
The minimum supply voltage is 8 V, and the maximum supply voltage is 52 V, providing flexibility in power supply options.
The supply current rating for this model is 1.4 A, which is essential for efficient operation in motor control applications.
This motor driver IC is designed to interface seamlessly with microcontrollers, DSPs, and FPGAs for precise motor control.
The L6225N is part of the L6225 series of motor driver ICs, which are engineered for driving motors and complex loads.
The maximum IGBT collector current rating for this model is 1.4 A, ensuring robust handling of motor loads during operation.
