Omron PCB Signal Relay 24V DC Coil 2A DPDT Contact Configuration G6AU-274P 24DC

Omron G6AU-274P 24DC is a high-quality PCB Signal Relay designed for precise and reliable switching applications in electrical and automation systems. Featuring a DPDT (double-pole double-throw) contact configuration, this relay is suited for signal switching tasks where dual contacts are needed.

The relay operates with a coil voltage of 24V DC, consuming a minimal coil power of 100mW, and has a coil resistance of 5760Ω, making it energy efficient. It supports a switching current of up to 2A with maximum switching voltages of 250V AC and 220V DC, enabling compatibility with a variety of signal-level circuits.

Its compact dimensions (20.2mm length, 10.1mm width, and 8.4mm height) allow for easy integration into printed circuit boards. The relay includes gold-plated contacts which offer durable electrical connectivity and reduce contact resistance to a low 50mΩ, enhancing signal integrity. Solder terminals provide reliable mounting on PCBs.

Designed to operate reliably within a wide temperature range from -40°C to 70°C, it is suited for industrial, telecommunications, automation, and manufacturing use cases. The relay is fully sealed and offers low magnetic leakage with an impulse withstand voltage of 1500V, ensuring robust protection against electrical disturbances.

Complying with RoHS standards and manufactured in Japan, this relay exemplifies quality and environmental responsibility. Omron’s G6A series relays, including this G6AU-274P 24DC model, are widely trusted in signal relay applications where precision and reliability are paramount.

DPDT contact configuration for dual switching capability. 24V DC coil voltage with low coil power consumption. Supports 2A switching current at up to 250V AC and 220V DC. Compact form factor with 20.2mm x 10.1mm x 8.4mm dimensions.

Gold plated contacts reduce resistance and increase durability. Wide operating temperature range from -40°C to 70°C. Fully sealed design with low magnetic leakage. RoHS compliant and manufactured in Japan.

This signal relay is ideal for applications in electrical circuits, automation equipment, telecommunications hardware, and other industrial control systems. Explore more high-performance Omron Signal Relays and related components to optimize your system design with EnvMart.
