TE Connectivity DIN Rail Power Relay 24V DC Coil 10A Switching Current SPST PCH-124L2M
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Height | 15.2mm |
| Length | 20mm |
| Model | PCH-124L2M |
| Width | 14mm |
| Mount Type | DIN Rail |
| Contact Material | Silver Alloy |
| Series | PCH |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Contact Rating | 5A @ 250Vac (IEC 61810), 10 A @ 125 Vac (UL 508) |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | Through Hole |
| Standards/Approvals | RoHS |
| Coil Resistance | 2.8kΩ |
| Coil Voltage | 24V dc |
| Coil Power | 200mW |
Key Features
- Designed for DIN rail mounting ensuring easy installation and integration.
- Silver Alloy contact material enhances electrical conductivity and durability.
- Operates efficiently within a temperature range of -40°C to 85°C.
- Low coil power consumption of 200mW with coil resistance of 2.8kΩ.
- High surge voltage capacity of 8000V (1.2/50μs) for robust performance.
- Contact rating supports 5A at 250Vac (IEC 61810) and 10A at 125Vac (UL 508) standards.
- RoHS compliant ensuring environmental and safety standards.
Product Description
TE Connectivity PCH-124L2M is a miniature DIN rail mount power relay featuring a 24V DC coil and SPST contact configuration. It is engineered for reliable switching in electrical, automation, and industrial control systems.
This relay is constructed with Silver Alloy contacts providing excellent electrical performance and longevity. It supports a switching current of 10A at 125Vac as per UL 508 and 5A at 250Vac according to IEC 61810 standards, making it suitable for a wide range of applications including HVAC systems, refrigeration units, and microwave ovens.
The relay operates efficiently with a coil power of 200mW and a coil resistance of 2.8kΩ. It withstands harsh environments with an operating temperature range from -40°C up to 85°C and high surge voltage capacity of 8000V (1.2/50μs), ensuring durability and safety under demanding electrical conditions.
Its compact form factor with dimensions 20 mm (L) x 14 mm (W) x 15.2 mm (H) permits installation in limited space setups. The relay mounts easily on standard DIN rails via its through-hole terminal type, facilitating quick deployment in industrial and commercial electrical assemblies.
Compact and sealed for durability and reliability. Suitable for industrial automation, HVAC, manufacturing, and commercial electrical systems. Compliant with modern environmental standards, ensuring safe use.
The package contains the PCH series DIN Rail Power Relay designed for precision and reliable switch operation in various electrical applications. Explore TE Connectivity products and other premium Power Relays and components in the EnvMart catalogue for your next project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a switching current of 10A at 125Vac according to UL 508 standards and 5A at 250Vac as per IEC 61810 standards.
The coil voltage for the PCH-124L2M is 24V DC.
The dimensions of this unit are 20 mm in length, 14 mm in width, and 15.2 mm in height.
It is designed for DIN rail mounting, allowing for easy installation and integration into electrical systems.
The relay operates with a low coil power consumption of 200mW.
The PCH-124L2M features a Single Pole Single Throw (SPST) contact configuration.
It operates efficiently within a temperature range of -40°C to 85°C.
The relay is constructed with Silver Alloy contacts, which enhance electrical conductivity and durability.
The coil resistance for the PCH-124L2M is 2.8kΩ.
This relay has a high surge voltage capacity of 8000V (1.2/50μs).
Yes, it is RoHS compliant, ensuring it meets environmental and safety standards.
This relay is suitable for various applications including HVAC systems, refrigeration units, and industrial automation.
