Samtec TSW Series Right Angle Through Hole Pin Header, 9 Contacts, 2.54 mm Pitch, 3 Row, Unshrouded TSW-103-08-G-T-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 400.0, 450.0, 500.0, 550.0V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 4.3A |
| Model | TSW-103-08-G-T-RA |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 3 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 1.52mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The pin header supports current up to 4.3A for reliable signal and power transmission.
- Housing is made from durable Polybutylene Terephthalate ensuring mechanical and thermal stability.
- Contact material is phosphor bronze with gold plating for corrosion resistance and optimal conductivity.
- Operating temperature range spans from -55°C to 125°C for diverse industrial environments.
- Tail pin length measures 1.52 mm and mating pin length is 5.84 mm for secure connections.
- This right-angle orientation pin header optimizes PCB layout and mounting flexibility.
- Suitable for industrial electronics requiring robust through-hole connectors.
- Offers many customization options for plating and ruggedized features for cost-performance balance.
Product Description
Samtec TSW-103-08-G-T-RA is a high-quality right angle through hole pin header engineered for industrial electronics applications. Its 9 male contacts arranged in three rows with a 2.54 mm pitch provide secure and efficient board-to-board connections.
The pin header's housing is constructed from high-grade Polybutylene Terephthalate, delivering excellent mechanical durability and thermal resistance. Contacts are crafted from phosphor bronze and plated with gold to ensure long-lasting performance, corrosion resistance, and high conductivity.
Designed for through-hole mounting and solder termination, this connector operates reliably across a wide temperature range from -55°C to 125°C, making it suitable for harsh and varied environmental conditions encountered in industrial, electronic manufacturing, and related sectors.
Key dimensions include a tail pin length of 1.52 mm and mating pin length of 5.84 mm, configured in a right angle orientation ideal for optimizing PCB layouts where space and connection angle are critical.
The TSW Series offers an extensive range of standard pin counts and terminal lengths, allowing customization to suit specific design requirements. Its unshrouded design facilitates easy inspection and assembly on PCB boards.
Supports a current rating of 4.3A for robust power and signal transmission. Housing made of Polybutylene Terephthalate providing mechanical and thermal stability. Phosphor bronze contact with gold plating ensures conductivity and durability.
Wide operational temperature range from -55°C to 125°C for varied environments. Right angle orientation for space-saving PCB layout solutions. Through-hole mount type with solder termination for secure installation. Unshrouded design for ease of use and flexibility.
Suitable for industrial electronics, manufacturing equipment, telecommunications, and other board-to-board connector applications. Explore the Samtec TSW Series for reliable industrial-grade right angle pin header connectors at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 4.3A for reliable signal and power transmission.
The pin header operates reliably within a temperature range of -55°C to 125°C, suitable for diverse industrial environments.
The contacts are made from phosphor bronze and are plated with gold to ensure optimal conductivity and corrosion resistance.
It features a pitch of 2.54 mm and has 9 male contacts arranged in three rows.
The tail pin length measures 1.52 mm, allowing for secure connections during installation.
This model utilizes through-hole mounting with solder termination for secure installation on PCBs.
The housing is constructed from Polybutylene Terephthalate, providing mechanical and thermal stability.
This pin header is designed as unshrouded, which facilitates easy inspection and assembly on PCB boards.
It is suitable for industrial electronics, manufacturing equipment, and telecommunications, among other board-to-board connector applications.
The mating pin length is 5.84 mm, ensuring compatibility with standard PCB layouts.
The TSW Series provides many options for optimizing cost and performance with various platings and ruggedizing features.
It belongs to the board-to-board connector system, designed for efficient connections between PCBs.
