Amphenol Limited MIL Spec Circular Connector 19 Way Brass Straight Female Contacts Wall Mount 500V AC 13A 97B-3100A-22-14S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V ac |
| Brand | Amphenol Limited |
| Colour | Olive |
| Orientation | Straight |
| Current | 13A |
| Model | 97B-3100A-22-14S |
| Mount Type | Wall Mount |
| Housing Material | Aluminium Alloy |
| Contact Material | Brass |
| Series | 97B |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Silver |
| Number of Contacts | 19 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shell Size | 22 |
| Military Standard | MIL-DTL-5015 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Shell Plating | Olive Drab Cadmium |
Key Features
- This MIL Spec circular connector supports 19 contacts with female gender.
- Rated for 13A current and 500V AC voltage for robust electrical performance.
- Features a straight orientation with olive drab cadmium plated aluminium alloy shell.
- Designed for wall mount installation with bayonet mating type ensuring secure connection.
- Operates effectively between -55°C and 125°C for wide environmental suitability.
- Contact material is brass with silver plating for enhanced conductivity and corrosion resistance.
- Incorporates strain relief and solder termination type for secure wiring.
- Meets MIL-DTL-5015 military standard for durability and reliability.
Product Description
Amphenol Limited 97B-3100A-22-14S MIL Spec Circular Connector is a high-quality, durable wall mount connector designed for industrial and military applications requiring reliable and space-efficient interconnection.
This connector features 19 female contacts made from brass with silver plating, ensuring excellent conductivity and corrosion resistance. The olive drab cadmium plated aluminium alloy housing provides robust mechanical and environmental protection, suitable for harsh conditions.
Rated for 13A current and 500V AC voltage, it supports critical power and signal transmission efficiently. The straight orientation with bayonet mating type ensures secure engagement and easy connection or disconnection. It conforms to MIL-DTL-5015 standard and is compatible with BS 9522 F0032 connectors.
The connector operates in a wide temperature range from -55°C to 125°C, meeting stringent military specifications. It includes features such as strain relief and solder bucket contacts, enhancing durability and installation reliability. The shell size 22 and standard connector size are designed for compatibility with threaded backshells suited for MS/aN fittings.
This MIL Spec circular connector supports 19 female contacts. Current rating of 13A at 500V AC voltage ensures robust electrical performance. Shell constructed of aluminium alloy with olive drab cadmium plating for durability.
Bayonet mating type and straight orientation provide secure and reliable mounting. Operation temperature range from -55°C to 125°C suits extreme environments. Contact plating of silver over nickel improves conductivity and corrosion resistance.
Includes strain relief and solder termination for secure cable connection. Meets MIL-DTL-5015 military standards and BS 9522 F0032 compatibility.
This circular connector is ideal for industrial, military, aerospace, and harsh environment applications requiring dependable electrical connections. Its durable design supports long-term reliability in demanding conditions.
Explore the wide range of MIL Spec Circular Connectors by Amphenol Limited on EnvMart for your industrial and electronic component needs.
Explore more products in our Industrial Circular Connector category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 13A and a voltage of 500V AC, ensuring robust electrical performance.
It operates effectively between -55°C and 125°C, making it suitable for extreme environmental conditions.
This unit is designed for wall mount installation, providing secure and reliable mounting options.
The housing is made from olive drab cadmium plated aluminium alloy, while the contacts are brass with silver plating for enhanced conductivity.
This model features 19 female contacts, allowing for multiple connections in a compact design.
It incorporates a solder termination type, which ensures secure wiring connections.
It utilizes a bayonet mating type, which ensures a secure connection and easy engagement or disengagement.
Yes, it meets the MIL-DTL-5015 military standard, ensuring reliability and durability in demanding applications.
The shell size for this model is 22, designed for compatibility with standard fittings.
The housing of this connector is olive in color, providing a distinctive appearance suitable for military applications.
It is ideal for industrial, military, aerospace, and harsh environment applications requiring reliable electrical connections.
This connector features female contacts, making it suitable for corresponding male connectors in various applications.
