Weidmüller BL Series 3-Contact Pluggable Terminal Block, 5.08 mm Pitch, 1 Row, Screw Connection, 400V, Copper 1943590000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 400V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | Right Angle |
| Current | 20A |
| Length | 13.16mm |
| Depth | 16mm |
| Width | 20.1mm |
| Housing Material | Copper Alloy |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 3 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 4mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screw |
| Lock and release-lever | tool-less locking and gentle releasing of the connector reduces the mechanical stress on the solder joints |
Key Features
- The connector features a copper alloy housing for durability and excellent conductivity.
- It supports a current rating of 20A for robust electrical performance.
- Terminal points are delivered already opened for quick and easy wiring (Wiring Ready).
- The integrated wire guard prevents dangerous under insertion of wires.
- Lock and release lever allows tool-less locking and gentle connector release to reduce solder joint stress.
- Right angle orientation suits various panel mounting applications.
- Power tools compatible plus/minus screw head enables global tool use.
- Fully RoHS compliant, ensuring environmental and safety standards.
Product Description
The Weidmüller 1943590000 is a BL Series pluggable terminal block designed for industrial, electronic component, and electrical applications requiring secure and efficient wire connections. This 3-contact terminal block features a 5.08 mm pitch and 1 row configuration, supporting voltages up to 400V and currents up to 20A.
Constructed with a robust copper alloy housing, the connector delivers enhanced durability and conductivity ideal for applications in power electronics, control panels, and automation systems. The terminal points come pre-opened (WIRE READY), enabling fast and reliable wiring, while the folded steel clamping yoke ensures wire retention and compensates for temperature-related expansions or contractions.
An integrated wire guard prevents under insertion of wires, significantly improving connection safety. The lock and release lever offers tool-less locking and gentle releasing of the connector, minimizing mechanical stress on solder joints during maintenance or replacement.
The terminal block features a right angle orientation and orange color coding, facilitating clear identification and installation in compact panel layouts. It uses a screw connection method compatible with globally standardized plus/minus screw heads, allowing the use of common power tools worldwide.
Fully RoHS compliant and manufactured in Germany, this BL series connector provides high-quality performance with an emphasis on security and processing quality. The connector is well suited for electronics manufacturing, industrial automation, and other electrical installations requiring efficient multi-contact terminal solutions.
The connector features a copper alloy housing for durability and excellent conductivity. It supports a current rating of 20A for robust electrical performance. Terminal points are delivered already opened for quick and easy wiring (Wiring Ready).
The integrated wire guard prevents dangerous under insertion of wires. Lock and release lever allows tool-less locking and gentle connector release to reduce solder joint stress. Right angle orientation suits various panel mounting applications.
Power tools compatible plus/minus screw head enables global tool use. Fully RoHS compliant, ensuring environmental and safety standards. Suitable for industrial and electronic equipment requiring reliable pluggable terminal connectors.
Explore more Pluggable Terminal Block solutions and Weidmüller products with EnvMart, your trusted partner for industrial electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block supports a voltage rating of 400V.
It has a maximum current rating of 20A, ensuring robust electrical performance.
This model features a pitch size of 5.08 mm.
The terminal block has 3 contacts.
It is designed with a right angle orientation, suitable for various panel mounting applications.
The wire connection method is screw-based, allowing for secure connections.
It accommodates a minimum wire size of 0.2 mm² and a maximum wire size of 4 mm².
The housing material is made from a copper alloy, providing durability and excellent conductivity.
Yes, it is fully RoHS compliant, ensuring it meets environmental and safety standards.
It includes terminal points that are pre-opened for quick wiring and a lock and release lever for tool-less locking and gentle connector release.
The dimensions are 13.16 mm in length, 16 mm in depth, and 20.1 mm in width.
This model is manufactured in Germany.
