Weidmüller BVZ Series Pluggable Terminal Block 3-Contact 7.62 mm Pitch 1 Row 1929940000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 40A |
| Length | 18.24mm |
| Depth | 23.1mm |
| Width | 41.2mm |
| Housing Material | Copper Alloy, Polyamide Fibreglass |
| Series | BVZ |
| Number of Rows | 1 |
| Pitch | 7.62mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 3 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 10mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 8AWG |
| Wire Connection Method | Screw |
Key Features
- Supports up to 40A current for reliable power handling.
- Right angle female connector with screw wire connection method.
- Compatible with wire sizes from 0.2 mm² to 10 mm² (24 AWG to 8 AWG).
- Constructed with copper alloy and polyamide fiberglass housing for durability.
- Rated for voltage up to 1kV ensuring safety in electrical systems.
- Includes touch-safe mating profile with >3 mm clearance for added operator safety.
- Designed for maximum operational reliability with a thermal derating up to 125 °C.
- Available with flange options including flange (F), screw flange (SF), and clip on screw flange (SFC).
Product Description
Weidmüller 1929940000 BVZ Series Pluggable Terminal Block is engineered for precision and reliability in electronic assemblies and industrial electrical connections. Featuring a 3-contact configuration at a 7.62 mm pitch, this single-row terminal block supports a current rating of 40A and voltage rating of 1kV, suitable for demanding electrical requirements.
The terminal block has a right angle female connector design equipped with a screw wire connection method to ensure a robust and secure electrical interface. It accommodates a wide range of wire sizes from 0.2 mm² (24 AWG) to 10 mm² (8 AWG), making it versatile for various wiring applications.
The housing is manufactured from a combination of copper alloy and polyamide fiberglass, delivering excellent mechanical strength and electrical insulation. Its compact dimensions of 18.24 mm in length, 41.2 mm in width, and 23.1 mm in depth facilitate easy integration into tight assembly spaces.
Safety is prioritized with a mating profile that offers a touch-safe clearance greater than 3 mm, reducing operator risks during installation and maintenance. The product also features maximum operational reliability with a thermal derating capability up to 125 °C, ensuring durability under thermal stress.
Additional features include unique coding for correct mating, preventing misconnection and ensuring system integrity. The terminal block series offers multiple flange mounting options such as flange (F), screw flange (SF), and clip on screw flange (SFC), enabling adaptable installation.
Supports 40A current and 1kV voltage for industrial electrical applications. Right angle female connector with screw clamping for reliable wire connection. Housing made of copper alloy and polyamide fiberglass for robustness and electrical insulation.
Accommodates wire sizes from 0.2 mm² to 10 mm² and 24 AWG to 8 AWG. Compact size for efficient use of panel space. Touch-safe mating profile ensures operator safety. Thermally derated up to 125 °C for extended reliability.
Multiple flange options for flexible mounting.
This terminal block is ideal for use in industrial machinery, electrical panels, automated systems, and power distribution applications where secure, touch-safe, and reliable connections are essential. Weidmüller products are known for their quality and compliance with RoHS standards, delivering trusted performance in critical installations.
Explore more from Weidmüller's range of Pluggable Terminal Blocks and other electronic components on EnvMart for comprehensive electrical system solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 40A, making it suitable for demanding electrical applications.
It is rated for a voltage of up to 1kV, ensuring safety in electrical systems.
The housing is made from a combination of copper alloy and polyamide fiberglass, offering mechanical strength and electrical insulation.
It has compact dimensions of 18.24 mm in length, 41.2 mm in width, and 23.1 mm in depth, facilitating easy integration into tight spaces.
It features a screw wire connection method, ensuring a robust and secure electrical interface.
It includes a touch-safe mating profile with a clearance greater than 3 mm, reducing operator risks during installation and maintenance.
It is designed for maximum operational reliability with a thermal derating capability up to 125 °C.
This model features a 3-contact configuration, suitable for various electrical connections.
Yes, it complies with RoHS standards, ensuring it meets environmental regulations.
The connector is designed in a right angle orientation, facilitating easier wiring in compact spaces.
