Phoenix Contact FMC 1.5/4-ST-3.5 Series Pluggable Terminal Block, 4-Contact, 3.5 mm Pitch, 1 Row, 160V, 8A Current 1952283
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 160V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 8A |
| Length | 21.9mm |
| Model | 1952283 |
| Depth | 7.75mm |
| Width | 14.75mm |
| Housing Material | Polyamide |
| Series | FMC 1.5/4-ST-3.5 |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 4 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.14mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Push-in Spring |
Key Features
- Features a push-in spring wire connection method for quick and tool-free wiring.
- Constructed with polyamide housing offering excellent electrical and thermal insulation.
- Supports wire sizes from 0.14 mm² (24 AWG) to 0.14 mm² (12 AWG).
- Operates at a rated voltage of 160 V and current carrying capacity of 8 A.
- Compact size with dimensions of 21.9 mm length, 14.75 mm width, and 7.75 mm depth.
- Designed as a single row, straight orientation terminal block with female connectors.
- Certified with UL94 V0 flammability rating for improved safety in industrial applications.
- Colour-coded green housing with corrosion-resistant tin-plated contacts ensures signal reliability.
Product Description
Phoenix Contact 1952283 FMC 1.5/4-ST-3.5 Series Pluggable Terminal Block is a high-quality electrical component designed for efficient and secure PCB connectivity. It offers a 4-contact configuration with a standard 3.5 mm pitch and single row, making it ideal for compact industrial and electronic applications.
The terminal block features a push-in spring wire connection system that allows quick and reliable conductor insertion without the need for additional tools, significantly reducing wiring time and complexity. Its polyamide housing provides excellent thermal and electrical insulation, safeguarding against short circuits and overheating risks.
This component supports conductor sizes from 0.14 mm² up to 0.14 mm² (24 to 12 AWG), accommodating a range of wiring requirements. Rated to operate at 160 V and 8 A, it is suitable for various control panel and electrical enclosure installations.
The housing is green coloured, which aids intuitive identification, and the contacts are tin-plated to resist corrosion, ensuring maximum conductivity and long-term signal integrity. With a rated surge voltage of 25 kV, this terminal block can withstand transient overvoltages typically encountered in industrial applications.
Its UL94 V0 flammability rating means that the terminal block stops burning within 10 seconds, enhancing workplace safety. The product dimensions are compact, measuring 21.9 mm in length, 14.75 mm in width, and 7.75 mm in depth, helping to save valuable space in PCB layouts and control cabinets.
Push-in spring connection enables tool-free wiring. Polyamide housing provides electrical and thermal insulation. Supports wire sizes 0.14 mm² (24 AWG) to 0.14 mm² (12 AWG). Tinned contacts resist corrosion and ensure reliable signal transmission.
Rated voltage of 160 V and current of 8 A for industrial applications. Green colour-coding for easy identification and workflow efficiency. Rated surge withstand voltage up to 25 kV. UL94 V0 flammability rating enhances safety.
Compact dimensions save space in installations.
This terminal block is suitable for industrial automation, manufacturing control panels, electronic equipment, power distribution units, and other similar environments where secure electrical connection and reliable performance are critical.
Explore more Phoenix Contact terminal blocks and related components on EnvMart for high-quality electronic solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block operates at a rated voltage of 160 V and has a current carrying capacity of 8 A.
It supports wire sizes from 0.14 mm² (24 AWG) to 0.14 mm² (12 AWG).
The terminal block features a 3.5 mm pitch and has 4 contacts.
The housing is constructed from polyamide, providing excellent electrical and thermal insulation.
It measures 21.9 mm in length, 14.75 mm in width, and 7.75 mm in depth.
It utilizes a push-in spring wire connection method for quick and tool-free wiring.
It has a UL94 V0 flammability rating, which enhances safety in industrial applications.
This model has a rated surge withstand voltage of up to 25 kV.
It is designed with a straight orientation and features female connectors.
The country of origin for this terminal block is Germany.
It is suitable for industrial automation, manufacturing control panels, electronic equipment, and power distribution units.
The green colour coding aids in intuitive identification, enhancing workflow efficiency during installation.
