Phoenix Contact IMC 1.5/4-STGF-3.81 Series Pluggable Terminal Block, 4-Contact, 3.81 mm Pitch, 320V, 8A Current 1858057
Specifications
| Country of Origin | Poland |
|---|---|
| Voltage | 320V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 8A |
| Length | 17.9mm |
| Model | 1858057 |
| Depth | 11.1mm |
| Width | 25.63mm |
| Housing Material | Polyamide |
| Series | IMC 1.5/4-STGF-3.81 |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 4 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.14mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Screw |
| PCB connector, nominal current | 8 A, rated voltage (III/2): 160 V, number of positions: 4, pitch: 3.81 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin |
Key Features
- Constructed with polyamide housing for durability and electrical insulation.
- Supports a nominal current of 8A and voltage rating of 320V.
- Features screw connection with tension sleeve for reliable wire attachment.
- Compatible with wire sizes ranging from 0.14 mm² (28 AWG) to 1.5 mm² (16 AWG).
- Designed in a straight orientation with tin-plated contact surfaces for corrosion resistance.
- Compact dimensions of 17.9mm length, 25.63mm width, and 11.1mm depth ensure space-saving PCB integration.
- Suitable for industrial, electronic, and electrical control applications requiring secure and pluggable connections.
Product Description
Phoenix Contact 1858057 IMC 1.5/4-STGF-3.81 Series Pluggable Terminal Block is a high-quality 4-contact PCB connector with a 3.81 mm pitch and 1 row configuration. It features polyamide housing, providing excellent mechanical strength and electrical insulation properties. The terminal block is designed to support a nominal current of 8 amperes and a voltage rating of 320 volts, suitable for a wide range of industrial and electronic control applications.
The wire connection is established using a screw connection method with a tension sleeve, ensuring a secure, reliable grip on wire sizes ranging from 0.14 mm² (28 AWG) to 1.5 mm² (16 AWG). Its straight orientation facilitates easy insertion and removal in PCB assemblies. The contact surfaces are tin-plated to improve corrosion resistance and electrical contact reliability.
Compact with dimensions measuring 17.9 mm in length, 25.63 mm in width, and 11.1 mm in depth, this pluggable terminal block is ideal for space-constrained PCB applications. Its green color coding helps visual identification during installation and maintenance. Manufactured in Poland, this component adheres to RoHS compliance standards, assuring environmentally responsible production.
Durable polyamide housing offering robust insulation. Rated for 8A current and 320V voltage for reliable operation. Screw connection with tension sleeve secures wire connection firmly. Supports a wide range of wire sizes from 0.14 mm² to 1.5 mm².
Tin-plated contacts enhance corrosion resistance and conductivity. Compact design fits efficient PCB layout requirements. Green color coding facilitates easy component identification. Compliant with RoHS environmental standards.
This terminal block is widely used in electronic components, power and connectors assemblies, and industrial automation systems. It provides a dependable connection solution for control cabinets, machinery, and equipment requiring modular electrical wiring with easy serviceability.
Explore more components in the Pluggable Terminal Blocks category on EnvMart for comprehensive solutions to your electrical connectivity needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 320V and supports a nominal current of 8A.
This terminal block is compatible with wire sizes ranging from 0.14 mm² (28 AWG) to 1.5 mm² (16 AWG).
The pitch of the contacts is 3.81 mm.
The housing is constructed from polyamide, providing electrical insulation and mechanical strength.
This model features 4 contacts.
The dimensions are 17.9 mm in length, 25.63 mm in width, and 11.1 mm in depth.
It utilizes a screw connection method with a tension sleeve for secure wire attachment.
The terminal block is designed in a straight orientation, facilitating easy insertion and removal in PCB assemblies.
Yes, it adheres to RoHS compliance standards, ensuring environmentally responsible production.
It is manufactured in Poland.
The terminal block is green, which helps with visual identification during installation and maintenance.
It is suitable for industrial, electronic, and electrical control applications requiring secure and pluggable connections.
